GMF100 DN50 RS485 electromagnetic chilled water flow meter price
Related products magnetic flow meter
Description magnetic flow meter
GMF100 intelligent electromagnetic flow meter is composed by sensor and transmitter. The product is a induction instrument and operates with Faraday law of electromagnetic induction for measurement volume flow of liquid medium with conductive rate ≥50 us/cm.
Detail show magnetic flow meter
Advantages electromagnetic flow meter
Specification magnetic flow meter
|
GMF100 Electromagnetic flow meter |
|
|
Medium |
Domestic water, industrial water, raw water, ground water, urban sewage, industrial wastewater, the processed neutral pulp, pulp slurry, etc |
|
Diameter |
DN6~DN2200mm |
|
Accuracy |
±0.5% |
|
Medium temperature |
<60℃ |
|
Nominal pressure |
GB 0.6MPa (DN700~DN2000) GB 1.0MPa (DN200~DN600) GB 1.6MPa (DN6~DN150) |
|
DIN PN16,PN25,PN40,PN63 |
|
|
JIS10K,20K,40K |
|
|
ANSI Class150,Class300,Class600, others can be customized |
|
|
Flow rate |
0.3~10m/s |
|
Straight pipe required |
Upstream ≥5DN,downstream ≥3DN |
|
Electrode |
316L (Suitable for domestic water, industrial water, raw water, underground water, sewage, etc.; not applicable to acid and alkali salt) |
|
Lining material |
Chloroprene rubber(CR), polyurethane rubber(PU) |
|
Installation way |
Carbon steel flange (standard), Stainless steel flange(optional) |
|
Body material |
Carbon steel (standard),Stainless steel(optional) |
|
Power supply |
220VAC/24VDC/lithium battery |
|
Signal output |
Pulse and 4~20mA; (if use lithium battery, without signal output) |
|
Communication |
RS485,GPRS,Hart |
|
Explosion-proof |
EXdeibmIICT3-T6 |
|
Protection proof |
IP65 (compact type); IP67,IP68(suitable for remote type) |
|
Work environment |
Ambient temperature:-20~+60℃,Ambient humidity:5%~90% |
|
Power |
<20W |
Flow rate provided shall be in consistent with the following chart:
Type selection magnetic flow meter
Note for type selection
1. The GMF intelligent electromagnetic flow meter series are mainly applicable for water flow measurement of industry water, city sewage system management, environment protection industries, etc.
2. Default installation part of GMF100 is flange connection, please inform us before ordering if other installation part is required.
