| Model: | ZY6015D |
|---|---|
| Brand: | Zonsky |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Laboratory Instrument |
| Label: | Bend Test Equipment , Robot Cable Test , Cable Bending Tester |
| Price: |
US $9999
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:26 Feb, 2021 |
1. Application
ZY6015D Robot Cable Bending Testing Machine/90 Degree Bending Testing Machine is suitable for TUV, VDE, UL and other high flexible cable testing requirements. The machine structure is a five-station structure. It is mainly used for repeated bending tests of metal materials to detect the plastic deformation performance and defects of metal wires in repeated bending tests. CRIA 0003.2-2016 "Industrial Robot Cable Part II: Test Method", "PFG2577/08.16 Standard Requirements.
2. Standards
CRIA 0003.2-2016, PFG2577/08.16
3. Main Technical Parameters
(1) Work power supply: AC220V, 50HZ.
(2) Motor power: 0.75kw
(3) Test speed: 0-60 times per minute can be adjusted (Note: Test cycle consists of four steps, i.e. around 1800 round trips for one time).
(4) Spindle rotation: ± 90 degrees, from left end (starting point) to right end (end point) is 180 degrees.
(5) Counter: 0 ~ 99999999 times can be set arbitrarily.
(6) Equipment size: W1050 * D600 * H900 mm.
| Payment Terms: | T/T, L/C |
|---|---|
