| Model: | YA-CS814 |
|---|---|
| Brand: | Usafe |
| Origin: | Made In China |
| Category: | Security & Protection / Alarm |
| Label: | smoke detector , fire alarm |
| Price: |
US $4.5
/ pc
|
| Min. Order: | 100 pc |
| Live Chat: | Last Online:19 Dec, 2018 |
Features
• Optical smoke chamber with high stability
• Network by Current network, N.O/N.C optional
• Adopted CMOS with low power consumption
• High adaptability to the ambient, with dustproof, moisture proof,
anti-white light, and high EMI immunity function
• DC12-35V input voltage
• Orientation differences: Mmax: Mmin<1.6
• Highlight dual color LED indication
• Anti-tamper switch
• Unique bracket design, easy installation
Specifications
| Model |
2-wire (YA-S814-2) |
3-wire (YA-S814-3) |
|
| Input Voltage | DC 12-35V | ||
| Static Current | ≤50uA (DC 12-35V) | ||
| Alarm Current | 40-80mA (DC 12-30V) | ||
| Operating Humidity | 10%-95% RH (Non coagulating) | ||
| Operating Temperature | -10°C- +55°C | ||
| Alarm Reset | Power off reset | ||
| LED Indication | Detecting: Green LED flash Alarm: Red LED ON | ||
| Installation | Ceiling mounted | ||
| Detecting Area | 60m² (with 4 meter height) | ||
| Detecting Sensitivity | m=0.5dBm-1 | ||
| Dimension | Φ100*45mm | ||
