| Model: | CPT 3000-212 |
|---|---|
| Brand: | Cosuper |
| Origin: | Made In China |
| Category: | Metallurgy , Mining & Energy / New Energy / Solar Energy |
| Label: | rv inverter , solar power inverter , inverter 12vdc |
| Price: |
US $450
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:27 Feb, 2020 |
Models: CPT3000
Output Power: 3000W
Surge Power: 9000W
DC Input Voltage: 12/24/48VDC
Output Voltage: 100/110/120VAC±5%, 220/230/240VAC±3%, 120-N-120/240VAC±3%
Output Frequency: 50/60Hz ±0.5%
Output Waveform: True sine wave(THD<5%)
Power Factor: 0.1~1
Efficiency: ≥85%
No Load Power: <10W(Power saving mode)
Transfer Time: <8ms
AC Range: 90~135VAC/165~265VAC
AVR Output(Opt): 100/110/120VAC±5% , 220/230/240VAC±3%
:Remote Control: CR-10/PTM-12 Option
Operating Temp: -20~50℃
Working Humidity: 20~90%RH
Storage Temp: -30~70℃
Cooling: Automatically controlled cooling fan
Weight (kg): 24
Size(mm): 525*250*185(L*W*H)
Application: The vehicle, Yacht, Solar power systems, Portable equipment, Power tools, Home and Office appliances
|
Models |
CPT1000 |
CPT1500 |
CPT2000 |
CPT3000 |
CPT4000 |
CPT5000 |
CPT6000 |
|
Output Power |
1000W |
1500W |
2000W |
3000W |
4000W |
5000W |
6000W |
|
Surge Power |
3000W |
4500W |
6000W |
9000W |
12000W |
15000W |
18000W |
|
DC Input Voltage |
12V24VDC |
12/24/48VDC |
24/48VDC |
||||
|
Output Voltage |
100/110/120VAC±5%, 220/230/240VAC±3%, 120-N-120/240VAC±3% splitphase |
||||||
|
Output Frequency |
50/60Hz ±0.5% |
||||||
|
Output Wavefoam |
True sine wave(THD<5%) |
||||||
|
Power Factor |
0.1~1 |
||||||
|
Efficiency |
≥85% |
||||||
|
No Load Power |
<10W(Power saving mode) |
||||||
|
Transfer Time |
<8ms | ||||||
|
AC Range |
90~135VAC/165~265VAC |
||||||
|
AVR Output(Opt) |
100/110/120VAC±5% , 220/230/240VAC±3% |
||||||
|
Remote Control |
CR-10/PTM-12 Option |
||||||
|
Safety |
UL458 LVD(EN60950) |
||||||
|
EMC |
FCC Part15 ClassA |
||||||
|
Operating Temp |
-20~50℃ |
||||||
|
Working Humidity |
20~90%RH |
||||||
|
Storage Temp |
-30~70℃ |
||||||
|
Cooling |
Automatically controlled cooling fan |
||||||
|
Weight (kg) |
15 |
17 |
20 |
24 |
35 |
43 |
45 |
|
Size(mm) |
455*250*185(L*W*H) |
525*250*185(L*W*H) |
650*250*165(L*W*H) |
||||
|
Application |
The vehicle, Yacht, Solar power systems, Portable equipment, Power tools, Home and Office appliances |
||||||
|
Models |
CPT1000 |
CPT1500 |
CPT2000 |
CPT3000 |
CPT4000 |
CPT5000 |
CPT6000 |
|
Output Power |
1000W |
1500W |
2000W |
3000W |
4000W |
5000W |
6000W |
|
Surge Power |
3000W |
4500W |
6000W |
9000W |
12000W |
15000W |
18000W |
|
DC Input Voltage |
12V24VDC |
12/24/48VDC |
24/48VDC |
||||
|
Output Voltage |
100/110/120VAC±5%, 220/230/240VAC±3%, 120-N-120/240VAC±3% splitphase |
||||||
|
Output Frequency |
50/60Hz ±0.5% |
||||||
|
Output Wavefoam |
True sine wave(THD<5%) |
||||||
|
Power Factor |
0.1~1 |
||||||
|
Efficiency |
≥85% |
||||||
|
No Load Power |
<10W(Power saving mode) |
||||||
|
Transfer Time |
<8ms | ||||||
|
AC Range |
90~135VAC/165~265VAC |
||||||
|
AVR Output(Opt) |
100/110/120VAC±5% , 220/230/240VAC±3% |
||||||
|
Remote Control |
CR-10/PTM-12 Option |
||||||
|
Safety |
UL458 LVD(EN60950) |
||||||
|
EMC |
FCC Part15 ClassA |
||||||
|
Operating Temp |
-20~50℃ |
||||||
|
Working Humidity |
20~90%RH |
||||||
|
Storage Temp |
-30~70℃ |
||||||
|
Cooling |
Automatically controlled cooling fan |
||||||
|
Weight (kg) |
15 |
17 |
20 |
24 |
35 |
43 |
45 |
|
Size(mm) |
455*250*185(L*W*H) |
525*250*185(L*W*H) |
650*250*165(L*W*H) |
||||
|
Application |
The vehicle, Yacht, Solar power systems, Portable equipment, Power tools, Home and Office appliances |
||||||
