| Model: | K200 |
|---|---|
| Brand: | SMD AUTOMATION |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Other Electrical & Electronic |
| Label: | led chip mounter , SMD MACHINE , smd mounter |
| Price: |
US $75000
/ set
|
| Min. Order: | 1 set |
| Live Chat: | Last Online:10 Nov, 2018 |
SMD machine high speed led chip mounter for FPC
Description:
1.K200 is the most popular LED tubes,led strips and LED panels mounter, equiped with 2 modules and 72 electric feeders,can mount 4 kinds of component meanwhile and the capacity can reach 120-160K CPH.
2. Adopt imported linear motor and grating ruler to locate the position, make sure the machine mounting with high speed and high accuracy.We promise to provide 2 years guarantee for the linear motor.
3.Integrated machine frame,welded into a whole by industrial class steel tubes and panels,greatly increase the machine's stability.
Specification:
|
Item |
Parameter |
|
Mounting head |
2 arms, 36 nozzles, 18 pieces nozzle per arm |
|
Mounting component range |
0805, 1206, 2835, 3014, 3528, 5050, 5630, 5730, RGB and other LED strip light and resistance |
|
Mounting Pattern |
Group picking and group mounting） |
|
Driver of mounting head(Y Axis) |
Linear motor(Magnetic levitation) |
|
Mounting height |
13mm |
|
PCB position |
CCD vision and MARK position |
|
PCB conveying speed |
320MM/S |
|
PCB conveying direction |
Front to Back |
|
Mounting accuracy |
±0.05MM |
|
Min mounting distance |
13MM |
|
Mounting speed |
70000CPH*2=140000CPH(Using 36 pieces nozzle condition) |
|
Rail size |
1300MM(L)-340mm（W) |
|
PCB size |
1200MM(L)-320mm（W) |
|
PCB thickness |
0.5mm-5.0mm |
|
FEEDER amount |
18（8mm)*4=72pcs;Electronic FEEDER |
|
Electric |
220V AC/50Hz/2 Phase |
|
Max power consumption |
3.0 KW |
|
Air pressure |
5kg |
|
Dimension |
(L)：2650mm |
|
(W)：2650mm |
|
|
(H)：1650mm |
|
|
Weight |
2000kg |
