Application
This pump is applied in pumping fresh water, waste water, river water, corrosive water, impurity water, dirty water, etc. Such as
1. Irrigation
2. Fire fighting
3. Industry water
4. Mine water pump
5.Transport water with salt or any other impurity things
6.Marine
Working Conditions
Rotating speed: 3600r/min, 1800r/min, 2960r/min, 1480r/min
Medium: clean water or other liquids similar to clean water in physical and chemical properties
Medium temperature: -10 ~ 80°C,400°C available under special design
Ambient temperature: Up to 40°C
Range of capacity:1.8~1200m3/h
Range of head: up to80m
Pump Construction
Casing/impeller:cast iron,stainless steel,copper,bronze,
Shaft: carbon steel 45#,stainless steel
Mechnical seal:graphite/silicon carbide/tungsten carbide
Advantages
1.Directly coupled, vibration proof and low noise.
2.Same diameter of inlet and outlet .
3.C&U bearing ,which is the most famous brand in China.
4.Circulating flow cooling ensure mechnical seal long life .
5.Small foundation required that will saving construction investment by 40-60%.
6.Excellent seal that is no leakage
Technical parameters:
|
Type |
flow
|
head
|
power
|
Efficiency
|
|
ZBC25-8-15 |
8 |
15 |
2.2 |
45 |
|
ZBC32-5-20 |
5 |
20 |
2.2 |
45 |
|
ZBC32-10-20 |
10 |
20 |
2.2 |
45 |
|
ZBC32-9-30 |
9 |
30 |
3 |
48 |
|
ZBC40-10-20 |
10 |
20 |
2.2 |
45 |
|
ZBC40-20-15 |
20 |
15 |
2.2 |
45 |
|
ZBC40-15-30 |
15 |
30 |
3 |
48 |
|
ZBC50-10-20 |
10 |
20 |
2.2 |
45 |
|
ZBC50-20-12 |
20 |
12 |
2.2 |
45 |
|
ZBC50-15-30 |
15 |
30 |
3 |
48 |
|
ZBC50-20-35 |
20 |
35 |
5.5 |
48 |
|
ZBC65-30-18 |
30 |
18 |
4 |
45 |
|
ZBC65-25-30 |
25 |
30 |
5.5 |
50 |
|
ZBC65-25-40 |
25 |
40 |
7.5 |
50 |
|
ZBC65-40-25 |
40 |
25 |
7.5 |
50 |
|
ZBC65-65-25 |
65 |
25 |
7.5 |
52 |
|
ZBC80-40-16 |
40 |
16 |
4 |
50 |
|
ZBC80-40-25 |
40 |
25 |
7.5 |
50 |
|
ZBC80-25-40 |
25 |
40 |
7.5 |
50 |
|
ZBC80-65-25 |
65 |
25 |
7.5 |
52 |
|
ZBC80-80-35 |
80 |
35 |
15 |
45 |
|
ZBC80-40-50 |
40 |
50 |
18.5 |
50 |
|
ZBC80-50-60 |
50 |
60 |
22 |
55 |
|
ZBC100-100-15 |
100 |
15 |
7.5 |
50 |
|
ZBC100-80-20 |
80 |
20 |
7.5 |
53 |
|
ZBC100-100-20 |
100 |
20 |
11 |
53 |
|
ZBC100-100-30 |
100 |
30 |
22 |
53 |
|
ZBC100-80-45 |
80 |
45 |
30 |
55 |
|
ZBC100-80-60 |
80 |
60 |
37 |
53 |
|
ZBC100-80-80 |
80 |
80 |
45 |
50 |
|
ZBC125-120-20 |
120 |
20 |
15 |
55 |
|
ZBC150-180-14 |
180 |
14 |
15 |
60 |
|
ZBC150-180-20 |
180 |
20 |
22 |
60 |
|
ZBC150-180-30 |
180 |
30 |
37 |
65 |
|
ZBC150-180-38 |
180 |
38 |
55 |
45 |
|
ZBC200-280-14 |
280 |
14 |
22 |
65 |
|
ZBC200-280-20 |
280 |
20 |
37 |
62 |
|
ZBC200-300-25 |
300 |
25 |
45 |
59 |
|
ZBC200-280-28 |
280 |
28 |
55 |
55 |
|
ZBC250-420-20 |
420 |
20 |
55 |
61 |
|
ZBC300-800-14 |
800 |
14 |
55 |
65 |
More specifications, please contact me.
Mail ID：Lisa@borrapump.com
Tel: +86 57767193977.
