REF:PZX-1005
100Ω UTP 4pairs STRANDED cable category5e - 100MHz - PVC sheath
COLOUR:
BLUE-WHITE/BLUE
ORANGE-WHITE/ORANGE
GREEN-WHITE/GREEN
BROWN-WHITE/BROWN



CABLE DESCRIPTION

1-CONDUCTOR PARAMETER UNIT VALUE
TYPE:STRANDED-Solid Bare copper Max.linear tesistance. Ω/km ≤100
DIAMETER:0.50mm±0.005mm
AWG:24 Mutual capacity(nom.) pF/m 60

2-INSULATION
TYPE:HDPE Characteristic impedance (1 at 100 MHz) Ω 100±15
DIAMETER:0.88mm±0.02mm

3-RIP CORD VELOCITY OF PROPAGATION (f＞1MHz) %of c 66
YES
Marking
4-OUTER JACKET
TYPE:PVC
COLOUR:GRAY E243826-UL CM 4Pair UTP Cat.5e 24AWG metric markings
THICKNESS:≥0.5mm
EXTERNAL DIAMETER:5.1mm±0.2mm

ELECTRICAL CHARACTERISTICS

Frequency (MHz) Return loss(dB) Attenuation (dB/100m) NEXT (dB) PSNEXT (dB) ELFEXT (dB) PSELFEXT (dB)
1 20.0 2.40 65.3 62.3 63.8 60.8
4 23.0 4.40 56.3 53.3 52.0 49.0
10 25.0 6.80 50.3 47.3 44.0 41.0
16 25.0 8.50 47.2 44.2 39.9 36.9
20 25.0 9.60 45.8 42.8 38.0 35.0
25 24.3 9.60 44.3 41.3 36.0 33.0
31.25 23.6 12.00 42.9 39.9 34.1 31.1
62.5 21.5 17.40 38.4 35.4 28.1 25.1
100 23.6 22.40 35.3 32.3 24.0 21.0
OTHER CHARACTERISTICS

Working Temperature: -20℃ to +60℃
Bending radius:≥10×out diameter TIANZHAO No.38 East Xiaotuanpu Road, Guanhaiwei, Cixi China
ISO/IEC 11801 TIA/EIA 568-C.2 Tel:(086)574 6366 9978 Fax(086)574 6366 1333
RoHS 2011/65/EU REACH EC 1907/2006 Site:http//www.cntianzhao.com
