| Model: | QT4-40 |
|---|---|
| Brand: | KAIDONG |
| Origin: | Made In China |
| Category: | Industrial Supplies / Construction Machine |
| Label: | block making machine , hollow block machine , price block machine |
| Price: |
US $3800
/ set
|
| Min. Order: | 1 set |
| Live Chat: |  | Last Online:06 Jan, 2022 |
concrete moulding hollow price fully automatic block making machine
maker machines cement brick making machine small manufacturing block plant manual block making machine
1. QT4-35B production capacity
|
No |
Size(LxWxH) |
Pcs/Mould |
Pcs/Hour |
Pcs/Shift |
|
1 |
400x200x200mm |
4 |
300 |
2400 |
|
2 |
400x100x200mm |
7 |
525 |
3675 |
|
3 |
400x150x200mm |
5 |
375 |
3000 |
|
4 |
400x250x200mm |
3 |
225 |
1800 |
2. QT4-35B forming technical parameters
|
Dimension of host machine |
1350×1460×1700mm |
Total machine power |
16.3KW |
|
Moulding period |
40S |
Vibration force |
30KN |
|
The size of the pallet |
850×450×25mm |
Workshop area |
60m2 |
|
Weight of the machine |
About 1.5T |
Mixer model |
KQ350 |
|
Voltage |
380V/415V/440V |
|
|
3.KQ350 mixer
|
No. |
Item |
Specification |
|
01 |
Model |
JD350 |
|
02 |
Charge volume(L) |
0.35 m3 |
|
03 |
Discharge volume(L) |
0.56 m3 |
|
04 |
Capacity(m3/h) |
≥4m3/h |
|
05 |
Max diameter(pebbles/break stone)mm |
40mm |
|
06 |
power |
7.5 KW |
|
07 |
Machine diameter |
1200mm |
|
08 |
weight |
0.42Ton |
4.Belt conveyor:
|
Item |
Specifaction |
|
Length |
6000mm |
|
Width |
500mm |
|
Speed (m/min) |
1.25 m/min |
|
Specification (ton/hour) |
30-40 ton/hour |
|
power(kw) |
1.1kw |
| Payment Terms: | TT/LC |
|---|---|
