No.

Item

Specification

1

The external dimension of the Rack

The dimension: L2700mm x D1000mm x H850mm (1 set)

  2

     The rack

The rack is made of welding 50# square box section. The bottom of rack has the truckle and foot cup. The height is adjustable. The rack is sealed by the plate,The structure is compact and generous.

3

The Conveyor Chain

The conveyor chain use special chain of automatic line. the pitch is 50.8mm,the total length is 6.4m. Each two pitch distance use one special fixture for the product.

  4

The Motor

The motor use Taiwan imported 0.5HP gear reducer motor to transmission. The speed of

chain is adjusted by adopting 1HP ZONCN frequency transformer. The chain speed is adjustable within 0.1m/min- 5m/min. The frequency control of the motor speed  is energy saving.

  5

The Friction Rotation Devise

It has two sets of special friction system, The motor adopts 200W electronic speed regulating motor. It can positive and negative rotation.

6

The Electronic Control

The electronic control is mainly use China famous brand CHINT brand.The indicator light, the switch,relay and contacts are equipped with the overload protection.The parts of Electronic Control is placed in the below of racks.

7

The surface treatment

Computer white electrostatic powder coating

8

Paint and Oil Feeding System

1. The automatic spray-gun use Japan ANEST IWATA WA-101 automatic spray gun. The caliber is 1.0mm. The qty of the guns is six. A set of adjustable support brackets is equipped.

2. Two sets of trisection diaphragm pumps are equipped.

3. It is equipped with relative oil pipe, Air pipe, pressure regulating valve,oil-water separator and a set of electric magnetic Valve.
