| Model: | TIG ER70S-6 |
|---|---|
| Brand: | Stone bridge |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Welding Solders |
| Label: | co2 welding wire , tig welding wire , tig er70s-6 |
| Price: |
US $1000
/ Ton
|
| Min. Order: | 23.76 Ton |
| Live Chat: |  | Last Online:25 Jan, 2024 |
CO2 Gas Shielded
Welding Wire TIG ER70S-6(SG2) Welding wire Introduction:
1. Available size: , 1.6mm.
2. Available packing: 10kg/bag
Precision layer wound on plastic spool, each spool in a box, then boxes on wooden pallet.
We could do according to the customers' request .
3. Application:
1). mineral machine, engineering machinery, shipping building , oil pipeline equipment, pressure vessels, steel constructions.
2). welding of other 500Mpa level carbon steel and low alloy steel.
3). high-speed welding of light gauge plate and pipe line steel.
4. Detailed description:
CO2 gas shielded mig welding wire is also called Co2 welding wire, mig welding wire,
solid welding wire which is widely used in common steel welding. This kind of welding wire
has excellent mechanical performance such as fast depositing speed, high depositing efficiency,
stable arc, little splash, beautiful seam, which is suitable for all-position welding work.
Packaging & Shipping
Detailed Specifications
for CO2 Gas Shielded Uae tig Welding Wire ER70S-6(SG2):
Chemical Composition of Welding Wire(%):
| C | Mn | Si | S | P | Cu |
| 0.06~0.15 | 1.40~1.85 | 0.80~1.15 | ≤ 0.035 | ≤ 0.025 | ≤ 0.50 |
Mechanical Properties of Deposited Mental: (shielding gas:CO2):
| Test Item |
Tensile Strength (MPa) |
Yield Strength (Mpa) |
Elongation
(%) |
Impact value
(J) |
Temperature
(%) |
| Guarantee Value | ≥ 500 | ≥ 420 | ≥ 22 | ≥ 27 | -30°C |
Reference Current (DC+):
|
Wire Size(mm) |
Welding Current(A) |
CO2 Flow Rate(L/min) |
| φ 0.8 | 50~180 | 15 |
| φ 1.0 | 70~240 | 15~20 |
| φ 1.2 | 80~350 | 15~25 |
| φ 1.6 | 120~450 | 20~25 |
