FEATURES & BENEFITS 

Two kinds of throttle control forms, manual control and foot pedal control, which greatly facilitates the operation. 

Standard with a low temperature engine start device to ensure quick start in winter.

Easy to Maintain.

Engine Engine model XINCHAI 490 Rated power（Kw） 37 Rated speed (rpm) 2650 Displacement(L) 2.67 Main Specifications Rated load (Kg) 750 Bucket capacity (m3) 0.3 Max.Speed(Km) 6.0 Tire model 10-16.5 Hydraulic flow  (L) 70 Fuel tank capacity  (L) 70 Operating weight with bucket (Kg) 2900

Main Dimension Max. Operating height (mm) 3770 Height of the bucket hinge pin to the ground  (mm) 2810 Height of the cabin to the ground  (mm) 1600 Height of the  bucket to the ground  (mm) 2643 Overall length without bucket (mm) 2800 Overall length with bucket (mm) 3490 Dumping angle at Max. height (°) 40 Dumping height(mm) 2080 Dumping reach (mm) 700 Rollback of  bucket on ground (mm) 30 Rollback of  bucket at full height (°) 104 Wheelbase (mm) 991 Ground clearance (mm) 205 Departure angle (°) 20 Turning radius without bucket  (mm) 1228 Front turning radius (mm) 2010 Back turning radius (mm) 1746 Rear axle to bumper (mm) 1208 Wheel tread（Standard tires）(mm) 1450 Width（Standard tires）(mm) 1720 Bucket width (mm) 1740

OTHER MODELS AVAILABLE: XD1200, XD1500T

PLEASE CONTACT US FOR FULL PRODUCT CATALOG
