| Model: | P1.667 |
|---|---|
| Brand: | Megaki |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Components / Display Parts |
| Label: | led display , led screen , led |
| Price: |
-
|
| Min. Order: | 1 pc |
| Last Online:06 Sep, 2017 |
1.High-definitaion
2.Ultrathin and Handiness
3.Low light、high gary and High refresh
4.Low power consumption, low noise created, low transportation costs, and low installation costs
5.Seamless stitching: With our special connector design it is easy to reduce gaps while installing, creating a perfect display
6.Favorable effect: using dot to dot calibration technology makes the image clearer and the layering stronger
| Unit Module | Item | Parameter |
| Module Number | HX-P1.667-30S | |
| Module Size | 200MM*100MM | |
| Pixels Density | 360000dot/m2 | |
| Pixel Pitch | 1.667MM | |
| LEPackage Mode | SMD0707/LED | |
| Pixel Resolution | 120Dots(W)*60Dots(H) | |
| Module Thickness | 14.75MM(without cylinder）26.63MM(include cylinder) | |
| Module Weight | 0.4KG | |
| Drive Type | Constant Drive | |
| Brightness White Balance | ≥1200CD/m2 | |
| Bracket | Size | 200MM*300MM |
| Box | Dimension | 400MM*300MM |
| Power Supply | AC90-264V/hz47-63（HZ） | |
| Screen Resolution | 240Dots*180Dots | |
| Best Viewing Distance | 2M-15M | |
| Best Viewing Angle | 160°（W）160°（H） | |
| Temperature | storage: -35℃/+85℃ | |
| Operation Humidity | 10%-75% | |
| Power | Working Voltage | AC220V±10% |
| Average Power Consumption | ≤233W/m2 | |
| Max Power Consumption | ≤900W/m2 | |
| Control System | Control Method | Synchronization |
| Driving Device | Constant Drive | |
| Technical Parameters | Refresh Frequency | ≥2000HZ |
| Frame Frequency | 50&60HZ | |
| Luminance Level/Color | RGB256 | |
| Gray Level | 16384 |
