| Model: | UL2464 |
|---|---|
| Brand: | WCH Cable |
| Origin: | Made In China |
| Category: | Computers & AV Digital / Computer Components / Computer Cable |
| Label: | cable , computer cable , pvc cable |
| Price: |
US $0.123
/ meter
|
| Min. Order: | 3050 meter |
| Live Chat: |  | Last Online:27 Mar, 2024 |
PVC Computer Cable UL2464
1. Tinned stranded or bare annealed copper conductor.
2. Insulation material: PP, PVC, SR-PVC, HDPE, FR-PE.
3. Rated temperature: 80C.
4. Rated voltage: 300V.
5. Uniform insulation wall thickness for easy stripping and cutting.
6. UL VW-1 and CSA FT-1/FT-2 vertical flame test verified.
7. Jacket material: PVC.
8. Standard executed: Appliance Wiring Material UL758
9. 100% RoHS compliant.
10. Outstanding feature: Most popular UL style, RoHS Compliant.
Application
Internal wiring of electronic equipment and appliances.
| UL Style | Cores | Conductor | Insulation Thickness | Jacket Thickness | Overall Diameter | Stanard
Put-Up |
Conductor Resistance at 20°C | |
| AWG | No/mm | mm | mm | mm | Feet/Roll | Ω/KM | ||
| UL2464 | 2 | 18 | 34/0.178 | 0.40 | 0.80 | 5.8±0.15 | 1,000 | 23.2 |
| UL2464 | 3 | 28 | 7/0.127 | 0.25 | 0.80 | 3.9±0.15 | 1,000 | 23.2 |
| 26 | 7/0.160 | 0.25 | 0.80 | 3.9±0.16 | 1,000 | 150 | ||
| 24 | 11/0.160 | 0.25 | 0.80 | 4.2±0.15 | 1,000 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 0.80 | 4.7±0.15 | 1,000 | 59.4 | ||
| 18 | 34/0.178 | 0.40 | 0.80 | 6.0±0.20 | 1,000 | 23.2 | ||
| UL2464 | 4 | 28 | 7/0.127 | 0.25 | 0.80 | 3.9±0.15 | 1,000 | 239 |
| 26 | 7/0.160 | 0.25 | 0.80 | 4.2±0.15 | 1,000 | 150 | ||
| 24 | 11/0.160 | 0.25 | 0.80 | 4.5±0.15 | 1,000 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 0.80 | 5.1±0.15 | 1,000 | 59.4 | ||
| 18 | 34/0.178 | 0.40 | 0.85 | 7.1±0.20 | 1,000 | 23.2 | ||
| UL2464 | 5 | 28 | 7/0.127 | 0.25 | 0.80 | 4.2±0.15 | 1,000 | 239 |
| 26 | 7/0.160 | 0.25 | 0.80 | 4.5±0.15 | 1,000 | 239 | ||
| 24 | 11/0.160 | 0.25 | 0.80 | 4.9±0.15 | 1,000 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 0.80 | 5.5±0.15 | 1,000 | 59.4 | ||
| 18 | 34/0.178 | 0.40 | 0.85 | 7.3±0.15 | 500 | 23.2 | ||
| UL2464 | 6 | 28 | 7/0.127 | 0.25 | 0.80 | 4.5±0.15 | 1,000 | 239 |
| 26 | 7/0.160 | 0.25 | 0.80 | 4.8±0.15 | 1,000 | 150 | ||
| 24 | 11/0.160 | 0.25 | 0.80 | 5.2±0.15 | 1,000 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 0.80 | 5.8±0.15 | 1,000 | 59.4 | ||
| UL2464 | 7 | 28 | 7/0.127 | 0.25 | 0.80 | 4.5±0.15 | 1,000 | 239 |
| 26 | 7/0.160 | 0.25 | 0.80 | 4.8±0.15 | 1,000 | 150 | ||
| 24 | 11/0.160 | 0.25 | 0.80 | 5.2±0.15 | 1,000 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 0.80 | 5.8±0.15 | 1,000 | 59.4 | ||
| UL2464 | 8 | 28 | 7/0.127 | 0.25 | 0.80 | 4.8±0.15 | 1,000 | 239 |
| 26 | 7/0.160 | 0.25 | 0.80 | 5.1±0.15 | 1,000 | 150 | ||
| 24 | 11/0.160 | 0.25 | 0.80 | 5.5±0.20 | 1,000 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 0.85 | 6.3±0.15 | 1,000 | 59.4 | ||
| UL2464 | 9 | 28 | 7/0.127 | 0.25 | 0.80 | 5.1±0.20 | 1,000 | 239 |
| 26 | 7/0.160 | 0.25 | 0.80 | 5.4±0.20 | 1,000 | 150 | ||
| 24 | 11/0.160 | 0.25 | 0.85 | 5.8±0.20 | 1,000 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 0.85 | 6.7±0.20 | 1,000 | 59.4 | ||
| UL2464 | 10 | 28 | 7/0.127 | 0.25 | 0.80 | 5.2±0.20 | 1,000 | 239 |
| 26 | 7/0.160 | 0.25 | 0.80 | 5.7±0.20 | 1,000 | 150 | ||
| 24 | 11/0.160 | 0.25 | 0.85 | 6.2±0.20 | 1,000 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 0.85 | 6.8±0.20 | 1,000 | 59.4 | ||
| UL2464 | 15 | 28 | 7/0.127 | 0.25 | 0.85 | 5.8±0.20 | 1,000 | 239 |
| 26 | 7/0.160 | 0.25 | 0.85 | 6.4±0.20 | 1,000 | 150 | ||
| 24 | 11/0.160 | 0.25 | 0.85 | 6.9±0.20 | 1,000 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 0.85 | 7.8±0.20 | 1,000 | 59.4 | ||
| UL2464 | 25 | 28 | 7/0.127 | 0.25 | 1.00 | 7.6±0.20 | 500 | 239 |
| 26 | 7/0.160 | 0.25 | 1.00 | 8.0±0.20 | 500 | 150 | ||
| 24 | 11/0.160 | 0.25 | 1.00 | 8.6±0.20 | 500 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 1.00 | 10±0.25 | 500 | 59.4 | ||
| UL2464 | 37 | 28 | 7/0.127 | 0.25 | 1.00 | 8.3±0.20 | 500 | 239 |
| 26 | 7/0.160 | 0.25 | 1.00 | 9.2±0.25 | 500 | 150 | ||
| 24 | 11/0.160 | 0.25 | 1.00 | 9.8±0.25 | 500 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 1.00 | 11.3±0.3 | 500 | 59.4 | ||
| UL2464 | 50 | 28 | 7/0.127 | 0.25 | 1.00 | 9.5±0.25 | 500 | 239 |
| 26 | 7/0.160 | 0.25 | 1.00 | 10.4±0.30 | 500 | 150 | ||
| 24 | 11/0.160 | 0.25 | 1.00 | 11.4±0.30 | 500 | 94.2 | ||
| 22 | 17/0.160 | 0.25 | 1.00 | 12.9±0.30 | 500 | 59.4 | ||
The demonstrated parameters for reference only. Please consult our customer service to customize any other parameter you demand.
