| Model: | - |
|---|---|
| Brand: | ROEWISH |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machine Hardware / Valves |
| Label: | angle valve , pneumatic angle , angle seat valve |
| Price: |
US $39
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:07 Aug, 2017 |
Technical Data:
Fluid Pressure: Max 1.6MPa(232psi)
Control Pressure: 0.3-0.8MPa(43.5-116psi)
Control Fluid: Neutral gas,Air
Actuator Size: 27mm,32mm,40mm,50mm,63mm,80mm,100mm,125mm
Applicable Fluid: Water, Alcohol, Oil, Dye, Steam, Neutral gas or liquid, Organic solvent, Acid and lye
Fluid temperature: -10oC-+180oC, 25oC-+220oC
Ambient temperature: -10oC-+80oC
Control Type: Normally closed, Normally open, Double acting
Connection: Threaded(BSP. BSPT, NPT), Welded, Flanged, Tri-clamp
Main Materials :
Body Material: CF8M(SS316), CF8(SS304)
Seals Material: PTFE
Actuator Material: PPS, CF8 (SS304)
Applications:
Beer& Drink Filling Machinery
Textile printing& Dyeing
Gas industry
Pharmacy& Medical Equipment
Chemical industry
Disinfection
Frothing Equipment
Water/sewage Disposal
Advantages:
1.Large Flux, low Resistance, No Water-hammer Y-type Shape Enlarged the Flowing Section, which Could Raise the Flux by 30% and Make Flow More Smooth
2.Super Long Life.
3.Which Help the Stem Adjust and Lubricate Itself Automatically.
4.the Cylinder Material is Stainless Steel.Lubricating Automatically, 360 Rolling Freely.
