| Model: | 25*50*4m |
|---|---|
| Brand: | Kenten |
| Origin: | Made In China |
| Category: | Construction & Decoration / Other Construction Materials |
| Label: | wedding tent , wedding marquee , outdoor wedding tent |
| Price: |
US $40000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:28 Mar, 2018 |
Aluminum structure tent
A shape structure tent
Size of cross section of the main profile: 201*111*4mm
Frame spec.:
Span width: 25m
Eave height: 4m
Ridge height: 8.14m,
Roof pitch: 18°
Bay spacing: 5m
Max wind loading:100km/h
Frame material: hard pressed extruded aluminum F27 (6005,6061/T6)
Eave connection: Hot-dip galvanized steel twin plate
Cover material:polyester fabric, white color PVC coated, waterproof, anti-UV, frame retardant according to DIN4102/B1, NFP92503, M2, B1;
weight of the roof cover: 800~950g/sqm ( opaque PVC ),
weight of side wall cover: 650g/sqm ( translucent PVC).
Optional accessories:
PVC Window Side Walls
Lining & Curtain
Glass Door Units
Glass Wall System
ABS Solid Wall System
Transparent PC Solid Wall
Transparent PVC Cover and Side Wall Cover
Floor System, Lighting,
Weight plate,
Anchor and etc.
| Payment Terms: | T/T |
|---|---|
