T-650 10W DTMF VHF UHF TOT 2500MAH walkie talkie
10W/5W/2W Power Switch with Side-key operation
◊ Chinese/English Voice Announcement
◊ Wide/Narrow Bandwidth Selection 12.5KHz/25KHz
◊ CTCSS&DCS non-standard code
◊ Battery Saver
◊ Low Battery Alert
◊ Check battery capacity by handheld operation and will annouce the capacity in current status
◊ VOX on/off, VOX level setting, VOX delay time setting
◊ DTMF/PTT ID
◊ Busy Channel Lockout
◊ Scan, Auto scan, Priority Channel Scan, Scan Add, Scan Delete
◊ TX Power Level Adjustment by hand operation
◊ Monitor / Monitor Momentary
◊ Squelch level report, Squelch level adjustment
| General |
| Transmitter |
| Frequency Range |
136-174MHz&400-480MHz 136-174MHz&450-520MHz |
| Operating Temperature | -20ºC to +55ºC |
| Frequency Stability | ±2.5ppm |
| Memory Channel | 16 |
| Working voltage | 7.4 |
| Antenna Impedance | 50Ω |
| Operating Mode | simplex of co-frequency or alien |
| Dimensions | 135*70*38mm |
| Weight | 255g |
|
TRANSMIT PART |
| RF power | 10W |
| Modulate Mode | F3E |
| Max.Freq.Deviation | ≤5KHz |
| Remain Wave Radiation | ≤60db |
| Transmitting Current | ≤1000mah |
| Receiver Part |
| Sensitivity | <0.20uV(12dB SINAD) |
| Squeich Sensitivity | <0.20uV |
| Intermodulation Antijamming | 50db |
| Audio Power output | 500mW |
| Receiving Current | ≤100mh |
| Squelch Stangby | 20ma |
| Standard Accessories |
|
Item No. |
Quantity |
|
Portable radio |
1 |
|
Antenna |
1 |
|
Battery Pack |
1 |
|
Charger |
1 |
|
Belt Clip |
1 |
|
User's Manual |
1 |
| Item No. | Quantity |
| Portable radio | 1 |
| Antenna | 1 |
| Battery Park | 1 |
| Charger | 1 |
|
Belt Clip |
1 |
| User’s Mannual | 1 |
