Technical Parameter

·  Dimensions: 250Lx47Wx25.5H(mm)

·  Armature Plate Dimension: 180Lx38Wx11H(mm)

·  Holding Force: 280kg(600Lbs)

·  Input Voltage: 12 or 24VDC

·  Current: 12V/600mA or 24V/300mA

·  Signal Output: NO/NC/COM

·  LED: Red shows unlocked, Green shows locked

·  Time Delay: 0/3/6/9sec adjustable

·  Suitable：Wooden door,Glass door,Metal door,Fireproof door

Advantage

·  Collinear Load Test 280kg/ 600pounds

·  Dual Voltage 12 or 24 VDC(optional).

·  The Standard Voltage is 12VDC when Finished.

·  MOV Provides Reverse Current Protection.

·  Anti-Residual Magnetism Designed.

·  High Strength Material,Anodized Aluminum Housing.

·  Design without Mechanical Failure.

·  Increase the holding Force,Dual Insulative Housing.

​.  CE, RoHS, FCC and IP68 certification
