| Model: | 66963209 |
|---|---|
| Brand: | CHOIEO |
| Origin: | Made In China |
| Category: | Office Supplies / Education Appliances |
| Label: | breaking trainer , hydraulic breaking , vocational equipment |
| Price: |
US $2000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:05 Jan, 2019 |
PRODUCT COMPOSITION
• It adopts the brand new Santana 2000 braking system, including front brake master cylinder, rear brake
master cylinder, brake master cylinder, vacuum booster, brake disc, brake caliper, front wheel bracket
assembly, transparent brake pipe, movable rack and so on.
FUNCTIONAL CHARACTERISTICS
1. The working principle of automobile braking system can be fully demonstrated on this trainer.
2. It could be used for the assembly and disassembly training, all the components adopted are same as the
original car, such as the wheel bearing, which is durable and strong.
3. Equipped with vacuum pump, it can simulate the vacuum of engine, making the brake flexible and easy,
TECHNICAL PARAMETERS
1. Dimensions: 1200mm×800mm×900mm
2. Operation environment: Temperature -5°C~40°C, Humidity: ≤80%
3. Automobile type: Santana 2000
4. Weight: 80KGS
