Functionality

Withdrawal,Inquiry,Transfer, Change of PIN, Multimedia (optional), Mobile payment (optional), Bill payment (optional)

Specification

• User-interface

   15" TFT LCD display, voice guidance

   8 FDKs and / or touch display

   EPP keypad be compliant with PCI, vandal resistance

   Loudspeakers

• Card Reader

   Motorized hybrid or dip card reader, EMV certified

   Support magnetic/smart card

   Card retracted if not removed

   Card returned if power failed

• Dispenser

   Frictional bundle delivery

   Max. 60 notes per bundle

   Dispensing speed: 7 notes per second

   2-4 cassettes, up to 3000 notes per cassette

   Reject & retract bin

   Cassette lock (optional)

• Control Unit

   Intel core 2 Duo 3.0 CPU, 2G RAM

   250G HDD, DVD ROM (optional)

   Operating system: Window XP

• Printer

   Receipt printer: 76mm thermal graphic printer

   Journal printer: 80mm dot matrix or thermal printer

• Communication

   Standard TCP/IP

   Optional: dial-up, wireless, X.25, SNA/SDLC

• Security

   UL291 Standard level 1

   Dial combination lock mechanism

   Fraudulent device inhibitor (FDI)

   EPP shield

   Privacy filter (optional)

   Customer awareness mirror

   Built-in cameras

   Integrated media entry/exit indicators

• Optional

   Barcode reader

   Fingerprint reader

   Contact-less card reader

   Heat booster

   Electronic journal

• Operating Environment

   Voltage: 100V-240V AC, 50/60Hz

   Temperature:  0 oC to 40 oC (without heat booster)

                   -35 oC to 40 oC (with heat booster)

   Humidity: 20% to 95% Non-condensing

• Dimensions and Weight

   Dimension: 1595mm X 500mm X 874mm (H x W x D)

  Weight: approx. 400kg
