Refractory fused cast AZS Brick for Glass Melting Furnace
Refractory fused cast AZS Brick for Glass Melting Furnace is also known as corundum - oblique zircon products, the main chemical composition contains Al2O3 50% to 70%, ZrO2 20% to 40%, the rest of the SiO2. The main mineral composition is oblique zircon (ZrO2), corundum.
Advantages and Properties of refractory fused cast AZS Brick for Glass Melting Furnace:
1.Casted by melting raw material in the mold, then cooling and solidification.
2.Strong glass corrosion resistance and high thermal shock stability.
3.Good wear-resistance,drags-resistance and alkali corrosion resistance.
4.High-purity raw material, less pollution.
5.Top quality, long service time.
Chemical Index:
|
Physical chemical index |
41#fused Zirconia corundum brick |
|
|
SiO2 |
≤13.0 |
|
|
Al2O3 |
44--48 |
|
|
ZrO2 |
40--44 |
|
|
Na2O |
≤1.3 |
|
|
Fe2O3+TiO2+CaO+k2O |
≤2.5 |
|
|
Normal pressure strength(Mpa) |
350 |
|
|
Thermal expansion rate(%) |
0.8 |
|
|
Glass temperature C |
>1410 |
|
|
Glass corrosion resistance(1500 C 36H, common glass) |
≤1.2 |
|
|
Bulk density
|
Ordinary casting |
≥3.6 |
|
Inclined casting |
≥3.75 |
|
|
Non shrinkage casting |
≥3.9 |
|
|
0.2MPa Refractoriness under load C |
>1700 |
|
Application of refractory fused cast AZS Brick for Glass Melting Furnace:
Refractory fused cast AZS Brick for Glass Melting Furnace is widely used in the void free configuration:electrode blocks, submerged walls, throats, and in some cases melter sidewalls. Available as well, for sidewall application, in the specific "reinforced filling" version.
Packing details:
Refractory fused cast AZS Brick for Glass Melting Furnace is packaged with fumigated wooden pallet, using paper or non-woven fabrics between layers separated,plastic shrink film protected outside.finally using straps. Or as your requirements.
Shipping:
By vessel or train from Chinese ports.
Our Advantages
1) Whole production process lines from bauxite to varies grit sizes of brown fused alumina.
2) Strictly quality control system to guaranty a good quality.
3) All set of production certificates including ISO:9000, ISO:9001,ISO9001:2000
4) years reputation at mainland market.
5) Professional technical consultants to provide various industry solutions.
