| Model: | INJ-20F |
|---|---|
| Brand: | INDEXCNC |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Engraving & Etching Machine |
| Label: | fiber laser marker , laser mark machine , fiber laser |
| Price: |
US $3800
/ pc
|
| Min. Order: | 300 pc |
| Live Chat: | Last Online:06 Jun, 2017 |
Technical Parameters:
|
No |
Item Name |
Parameter |
|
1 |
Model |
INJ20F |
|
2 |
Laser Power |
20W |
|
3 |
Laser wavelength |
1064nm |
|
4 |
Laser type |
Fiber Laser |
|
5 |
Laser beam quality |
M2:1.5 |
|
6 |
Repeat Frequency |
30KHz-60KHz |
|
7 |
Repeat Positioning Accuracy |
0.005mm |
|
8 |
Min linear width |
0.01mm |
|
9 |
Marking Depth |
0.01-0.5mm |
|
10 |
Standard Marking Area |
110×110mm |
|
11 |
Cooling |
Air cooling |
|
12 |
Rated Power Consumption |
500W |
|
13 |
Operating Voltage |
110V- 240V/50-60 Hz/15A |
|
14 |
Gross weight |
35 kg |
| Payment Terms: | T/T,L/C |
|---|---|
