Expansion Diaphragm Tanks for Heating & Cooling Systems

Model:11 Series
Brand:Aqualeader
Origin:Made In China
Category:Construction & Decoration / Water Heating Hardware
Label:Diaphragm tanks , pressure tank , Expansion Vessels
Price: US $6 / pc
Min. Order:1000 pc
Inquire Now Add to Basket

Member Information

Detail

Taizhou Tianyang Electrical Co.,LTD.

Free MemberZhe Jiang - China
Live Chat:
点击这里给我发消息Last Online:25 Apr, 2017

Product Description

General Introduction

Diaphragm tanks are pressurized water vessels where the water and air are separated by a flexible diaphragm allowing the water to expand and absorb pressure surges.

In booster applications, diaphragm tanks can be used on both the discharge and the suction manifold. Connected to the suction manifold, a tank serves to counteract fluctuating inlet pressures.

Pressure in low flow periods
Diaphragm tanks are commonly used on the discharge manifold to provide water storage for the system in very low flow situations. It decreases the running time of the booster pumps, thereby making the system more energy effective.

Eliminates water hammer
Since the diaphragm is flexible, it is able to adjust to sudden pressure changes, thus counteracting water hammering.

When to use diaphragm tanks…
If low or no-flow conditions are expected, a diaphragm tank should be used to work in conjunction with the Stop Function of the booster system.

In areas where inlet pressure fluctuates, diaphragm tanks are often installed on the suction manifold to reduce damaging peak pressures.

Main Feature

Single diaphragm design 100% potable quality butyl.
Patented 316 stainless steel connection.
Virgin polypropylene liner, so no water touches plain steel.
Internal clench ring becomes more secure at higher pressures.
High quality two part polyurethane, epoxy primed paint finish
Brass stemmed air valve and O–ring sealed valve cap.
NSF standard 61, CE / PED, WRAS approvals.
Maximum temperature up to 90 °C.
Standard maximum pressure 150 PSI / 10 Bar.                                                                               Aqualeader ,we have appied 240 psi/16 bar
5 Year Warranty

Technical Parameter

Model Model Actual Capacity          Recommeded Max.Working Pressure  Connection BSP  Dimrnsion  Package
GWS Aqualeader GWS Aqualeader Connection  Tank Prechange Tank Body  Membrane Diameter  Height
Unit Liter Material Bar Material/Painting Material  Bar Inch mm mm mm
PWB-2V TY-11-0.5G 2 3 Stainless Steel SUS 316 2.0-2.5 Bar Steel/Two Layers Polyurethane Paint Finish Over An Epoxy Undercoating Butyl  10 1 130 210 640x260x235/10 Pcs
  TY-11-1.1G   4 Butyl  10 1 160 270 160x160x270
  TY-11-1.5G   5 Butyl  10 1 200 280 200x200x280
PWB-8V TY-11-2G 8 8 Butyl  10 1 200 340 200x200x340
  TY-11-3G   12 Butyl  10 1 220 360 230x230x370
  TY-11-4.5G-W   19 Butyl  10 1 270 400 270x270x380
PWB-18V TY-11-4.5G 18 19 Butyl  10 1 270 380 270x270x400
PWB-24V TY-11-6.3G 24 24 Butyl  10 1 270 450 270x270x450
PWB-35V TY-11-9.3G 35 36 Butyl  10 1 320 470 320x320x470
PWB-60V TY-14-11G 60 60 Butyl  10 1 395 640 395x395x640
PWB-80V TY-11-15.5G 80 80 Butyl  10 1 440 720 440x440x720
PWB-100V TY-14-22G 100 100 Butyl  10 1 440 830 440x440x830
PWB-150V TY-14-44G 150 200 Butyl  10 1 650 980 650x650x980
  TY-12-2G-W   8 Butyl  10 1 220 320 220x220x320
  TY-12-2G   8 Butyl  10 1 220 340 220x220x340
  TY-12-3G   12 Butyl  10 1 260 360 260x260x370
  TY-12-4.5G   19 Butyl  10 1 290 400 310x310x400
  TY-12-4.5G-W   19 Butyl  10 1 290 380 310x310x380
PWB-20H TY-12-6.3G 20 24 Butyl  10 1 295 460 310x310x460
PWB-60H TY-12-11G 60 60 Butyl  10 1 415 640 430x430x640

Price Terms:FOB Ningbo
Payment Terms:50% Prepaid And The Rest Will Be Paid By Telegraphic Transfer
Packing:Paper Box
Lead Time:25-35 Days
SKU:2500
Standards Certificate:CE,SGS,WATER MARK,WRAS,NSF 61

Product Image

Expansion Diaphragm Tanks for Heating & Cooling Systems 1
