P1.5 P2 P2.5 P3 P4 P5 P6 P7 P8 P10 P16 led screen display
Product Description
Quick Details
- Place of Origin: Sichuan, China (Mainland)
- Brand Name: EZCOM
- Model Number: P4
- Usage: Indoor
- Tube Chip Color: Full Color
- Display Function: Video
- Pixels: 4MM
- Screen Dimension: Customized Size, Can be Customized
- Pixel density: 62500dots/sqm
- Luminance: >1500~7500cd/sqm
- Pixel composition: SMD 3 in 1
- Led encapsulation: SMD
- View angle / °: 160H/160V
- Voltage: AC 220V
- IP Level: IP30~IP65
- Average of non-failure life: >10000H
- Life span: >100000H
Packaging & Delivery
Packaging Details: |
Polywood package or Aviation case |
Delivery Detail: |
Within 20 days
WHY US:
1. 10 years production experience, China leading LED screen manufacturer.
2. Each LED screen will do 4 days aging test before it being taken out of factory to ensure its quality.
3. We have complete industry chain from LED sealing to finished product so that we have high price competitive power.
4. We have done thousands of projects for different environment, upto now, customer satisfaction is 100%!
WE CAN GIVE YOU A REASONABLE PROPOSAL NO MATTER YOU PLACE ORDER FROM US OR NOT!
So if you have requirement for LED screen, Do contact us for a proposal.
Technical specification |
Product model |
Pixel pitch(mm) |
1.5 |
1.667 |
1.875 |
1.923 |
2 |
2.5 |
Pixel density(dot/m²) |
444444 |
360000 |
284444 |
270420 |
250000 |
160000 |
Pixel color |
RGB |
RGB |
RGB |
RGB |
RGB |
RGB |
LED |
SMD |
SMD |
SMD |
SMD |
SMD |
SMD |
View angle |
H:160°
V:160° |
H:160°
V:160° |
H:160°
V:160° |
H:160°
V:160° |
H:160°
V:120° |
H:160°
V:120° |
Brightness(cd/m2) |
>1500 |
>1500 |
>1500 |
>1500 |
>1500 |
>1500 |
Scan mode |
1/32 |
1/24 |
1/32 |
1/32 |
1/20 |
1/32 |
Control mode |
Syc. |
Syc. |
Syc. |
Syc. |
Syc. |
Syc. |
Color depth |
65536 |
65536 |
65536 |
65536 |
65536 |
65536 |
Scan freq(Hz) |
≥2400 Hz |
≥1920 Hz |
≥1920 Hz |
≥1920 Hz |
≥960 Hz |
≥720 Hz |
Frame freq(Hz) |
60 |
60 |
60 |
60 |
60 |
60 |
Module units size(mm) |
200x100 |
240x240 |
240x240 |
200x150 |
128X128 |
160X160 |
Module definition(dot) |
128x64 |
144x144 |
80x90 |
104x78 |
64X64 |
64X64 |
Cabinet(mm) |
800*600 |
480*480 |
480*480 |
800*600 |
512*512 |
640*640 |
Working voltage(V) |
AC 220 |
AC 220 |
AC 220 |
AC 220 |
AC 220 |
AC 220 |
Average consumption(W/m2) |
200 |
200 |
200 |
200 |
350 |
350 |
Max consumption(W/m2) |
500 |
500 |
500 |
500 |
700 |
700 |
IP level |
IP30 |
IP30 |
IP30 |
IP30 |
IP30 |
IP30 |
Working condition(℃/%RH) |
-20~50℃ |
-20~50℃ |
-20~50℃ |
-20~50℃ |
-15~45℃ |
-15~45℃ |
Storage condition(℃/%RH) |
-25~70℃ |
-25~70℃ |
-25~70℃ |
-25~70℃ |
-25~70℃ |
-25~70℃ |
MTBF |
10000 |
10000 |
10000 |
10000 |
10000 |
10000 |
Lifetime(H) |
100000 |
100000 |
100000 |
100000 |
100000 |
100000 |
Technical specification |
Product model |
Pixel pitch(mm) |
3 |
4 |
5 |
6 |
7.62 |
10 |
Pixel density(dot/m²) |
111111 |
62500 |
40000 |
27777 |
17222 |
10000 |
Pixel color |
RGB |
RGB |
RGB |
RGB |
RGB |
RGB |
LED |
SMD |
SMD |
SMD |
SMD |
SMD |
SMD |
View angle |
H:160°
V:120° |
H:160°
V:120° |
H:160°
V:120° |
H:160°
V:120° |
H:160°
V:120° |
H:160°
V:120° |
Brightness(cd/m2) |
>1500 |
>1500 |
>1500 |
>1500 |
>1500 |
>1500 |
Scan mode |
1/32 |
1/16 |
1/16 |
1/8 |
1/16 |
1/8 |
Control mode |
Syc. |
Syc. |
Syc. |
Syc. |
Syc. |
Syc. |
Color depth |
65536 |
65536 |
65536 |
65536 |
65536 |
65536 |
Scan freq(Hz) |
≥720 Hz |
≥960 Hz |
≥960 Hz |
≥960 Hz |
≥1080 Hz |
≥1080 Hz |
Frame freq(Hz) |
60 |
60 |
60 |
60 |
60 |
60 |
Module units size(mm) |
192X192 |
256X128 |
320X160 |
384X192 |
244X244 |
320X160 |
Module definition(dot) |
64X64 |
64X32 |
64X32 |
64X32 |
32X32 |
32X16 |
Cabinet(mm) |
512*512 |
640*640 |
640*640 |
768*768 |
1024*768 |
960*960 |
Working voltage(V) |
AC 220 |
AC 220 |
AC 220 |
AC 220 |
AC 220 |
AC 220 |
Average consumption(W/m2) |
350 |
350 |
300 |
350 |
350 |
350 |
Max consumption(W/m2) |
700 |
700 |
600 |
700 |
700 |
700 |
IP level |
IP30 |
IP30 |
IP30 |
IP30 |
IP30 |
IP30 |
Working condition(℃/%RH) |
-15~45℃ |
-10~50℃ |
-10~50℃ |
-10~50℃ |
-10~50℃ |
-10~50℃ |
Storage condition(℃/%RH) |
-25~70℃ |
-40~85℃ |
-40~85℃ |
-40~85℃ |
-40~85℃ |
-40~85℃ |
MTBF |
10000 |
10000 |
10000 |
10000 |
10000 |
10000 |
Lifetime(H) |
100000 |
100000 |
100000 |
100000 |
100000 |
100000C |
|
Product Image
Img 1
Img 2
Img 3
Img 4
Img 5
