| Model: | CFM-XJJ03 |
|---|---|
| Brand: | ChenFei |
| Origin: | Made In China |
| Category: | Industrial Supplies / Food, Beverage & Cereal Machine |
| Label: | sterilizer , jam sterilizer , pasteurizer |
| Price: |
US $30000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:30 Oct, 2017 |
Tubular sterilizer
Application
It is widely used for the sterilization of fruit juice, tea drinks, milk and virgin pulp and other liquid food.
Description
Automatic tubular UHT sterilizer is designed and produced absorbing in foreign advanced technology and adopting many years’ experience. The whole system adopts programmable control, operating system is image HMI, easy to know all running status of all components; control system takes the real-time control of temperature and data collection and storage. All valves, electric control system adopt well-known brands. It is easy to clean, with advanced structure, reliable usage.
UHT Sterilizer can carry out heating, heat preservation, heat recovery and cooling operations. At the phases of preheating section and sterilization, heat can be fully recycled. It adopts multi-phase to carry out heating, heat preservation, heat recovery and cooling operations, which can enhance the usage efficiency of heat energy.
In the whole process of sterilization, the temperature of the material are in full automatic control. When using the UHT sterilizer, according to user requirements the discharge temperature can be adjusted as per the sterilization filler requires.
Features
1. Main structure is made of 304 stainless steel
2. Thorough sterilization, low energy consumption
3. All connection with steam protection
4. Sterilization is stable and operation is simple
5. Independent control cabinet, HMI PLC control
6. With aseptic filling machine carry out CIP and SIP simultaneously
Tube-in-tube Sterilizer
Application
The machine is used for the sterilizing of tomato paste, onion paste, chill paste, strawberry paste, blackberry paste, carrot paste, peach paste, apricot paste etc.
Features
Low energy consumption, high heat exchanging efficiency,high capacity and easy cleaning
Technical Parameter
Model CFM-UHT-PP1.5 CFM-UHT-PP3 CFM-UHT-PP5
Capacity(L/H) 1500 3000 5000
Inlet temperature(℃) 25-40℃ 25-40℃ 25-40℃
Holding Time(s) 120-180 120-180 120-180
Sterilizing temperature(℃) 95-121℃ 95-121℃ 95-121℃
Outlet temperature(℃) 25-35℃ 25-35℃ 25-35℃
Cooling water T(℃) 30℃ 30℃ 30℃
Steam pressure 0.5MPa 0.5MPa 0.5MPa
Steam consumption `150Kg/h `210Kg/h `280Kg/h
Compressed air pressure 0.6MPa 0.6MPa 0.6MPa
Compressed air consumption 50L/H 50L/H 60L/H
machine size(LxWxH) 7000x2000x2000 7000x2000x2000 7000x2000x2000
Weight 1700kg 2000kg 2200kg
