| Model: | NF-816 |
|---|---|
| Brand: | NOYAFA |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Other Electronic Instrument |
| Label: | wire tracker , wire locator , undergroud wire trac |
| Price: |
US $26
/ pc
|
| Min. Order: | 30 pc |
| Live Chat: |  | Last Online:05 Aug, 2020 |
Item Specifics:
* Is_customized : Yes
* Brand Name : Noyafa
* Model Number : NF-816
* Place of Origin : Shenzhen.China
* Tracing type: Underground, Buried wires and Other Hidden wires
* Length range:up to 1000 feet
* Depth range: up to 3 feet
* Power : 9V Alkaline battery
* Certificates: CE
* Warranty : 1 Year
Main functions:
1. Trace and locate underground or in-wall wires;
2. Enables cables to be located before drilling ;
3. The detection range is 3 feet and cable length 3000 feet.
4. Widely applied in Pet fence
5. White LED Flash Light.
Technical indexes:
| NF-816 Transmitter specifications | |
| Tone frequency | 200kHz |
| The Max length distance | 1000 feet |
| The Max depth distance | 3 feet |
| The Max. working current | Less than 70mA |
| Tone mode | 1 Tone |
| Max. signal voltage | 15Vp-p |
| Signal display | Signal tone, Antenna |
| Voltage protection | AC 60V/DC 42V |
| Battery type | DC9.0V（NEDA 1604/6F22) x 1pc |
| Dimensions (LxWxD) | 49 x 135 x 33mm |
| NF-816 Receiver specifications | |
| Frequency | 200kHz |
| The Max. working current | Less than 70mA |
| Earphone jack | 1 |
| Battery type | DC9.0V（NEDA 1604/6F22) x 1pc |
| Dimensions (LxWxD) | 43 x 168 x 27mm
|
| Payment Terms: | TT/paypal |
|---|---|
