Forming Speed 15 m/min Cold Roll Forming Machine With TW-40*40

Model:TW-40*40
Brand:TECHWELL
Origin:Made In China
Category:Construction & Decoration / Shaped Building Material
Label:Sheet Roll , Metal Steel , Roof Sheet
Price: US $32000 / set
Min. Order:1 set
Inquire Now Add to Basket

Member Information

Detail

Wuxi Techwell Machinery Co.,Ltd

Free MemberJiang Su - China
Live Chat:Last Online:01 Aug, 2016

Product Description

Product Description:

1) This bracket channel forming machine line adopt galvanized steel coil production material to form profile L 40 * 40 * 7.5 through 3Ton hydraulic decoiler, pinch feeding, leveling, 1 group hydraulic punching, main roll forming, Hydraulic cutting and Non-power type support table.

2) The whole machine adopt PLC control, AC speed control by frequency inverter technology, to realize continuous auto production, which is the best desired machinery in steel structure and metal cold roll forming machinery industry.

3) Forming Speed: about 0-15 m/min ( excluding punching, cutting time);

4) The whole machine is fixed with mesh safety protection cover

5) All parts on shaft like roller, roller spacers, guiding column are chromium plating process



Main Specifications:

Main Technical Parameter
Suitable Material        Galvanized
Thickness 1.2-1.6mm
Coil width depend on profile
Forming Roller Stations 12
Diameter of Forming Shaft 70mm
                               Forming Speed                                                           0-15m/min
     Forming Roller Material                       GCr15 steel, coated with hard chrome 0.05mm
Cutter Material CR12Mov Mold steel, with quench treatment
Controlling system PLC with Touch screen & Inverter
Main Motor Power 11KW
     Cutting Power             4KW
Machine weight 7500Kgs










Product Image

Forming Speed 15 m/min Cold Roll Forming Machine With TW-40*40 1
Img 1
Forming Speed 15 m/min Cold Roll Forming Machine With TW-40*40 2
Img 2
Forming Speed 15 m/min Cold Roll Forming Machine With TW-40*40 3
Img 3
Forming Speed 15 m/min Cold Roll Forming Machine With TW-40*40 4
Img 4
Forming Speed 15 m/min Cold Roll Forming Machine With TW-40*40 5
Img 5
