| Model: | Holo 1500etc |
|---|---|
| Brand: | Holo |
| Origin: | Made In China |
| Category: | Industrial Supplies / Rubber & Plastics Machine |
| Label: | Air-cooled , Air-cooling , Hot Press |
| Price: |
US $6800
/ pc
|
| Min. Order: | 1 pc |
| Last Online:29 Jul, 2016 |
|
Tool Specifications |
LODO300 |
LODO600 |
LODO900 |
LODO1200 |
LODO1500 |
|
Effective length |
305 mm |
610 mm |
914 mm |
1219mm |
1524mm |
|
Effective width |
130 mm |
130 mm |
130 mm |
130mm |
130mm |
|
Weight lower part |
10 kg |
16 kg |
20 kg |
28.5KG |
32KG |
|
Weight upper part |
11 kg |
13 kg |
18 kg |
25.5KG |
30KG |
|
Total weight |
21 kg |
30 kg |
38 kg |
54KG |
62KG |
|
Length |
505 mm |
805 mm |
1105 mm |
1405mm |
1705mm |
|
Overall Height |
220 mm |
225 mm |
225 mm |
225mm |
225mm |
|
Overall Width |
250mm |
250mm |
250mm |
250mm |
250mm |
|
Max. pressure |
2Bar |
2Bar |
2 Bar |
2bar |
2bar |
|
Max. temperature |
200 ˚C |
200 ˚C |
200 ˚C |
200 ˚C |
200 ˚C |
|
Dimensions for transport |
712 x 352 x280 mm |
1012 x 352 x 280 mm |
1312 x 352 x 280 mm |
1612 x 352 x 280 mm |
1912 x 352 x 280 mm |
|
Weight for transport |
26 kg |
35 kg |
43 kg |
84KG |
96KG |
|
Power |
1.2KW |
3.2KW |
4.5KW |
5.8KW |
7KW |
