| Model: | 6FYDT-50T |
|---|---|
| Brand: | Huanpai |
| Origin: | Made In China |
| Category: | Agriculture & Foods / Processed Food / Other Processed Food |
| Label: | wheat processing , wheat milling , wheat grinder |
| Price: |
US $65000
/ set
|
| Min. Order: | 1 set |
| Live Chat: | Last Online:17 Sep, 2020 |
commercial maize grinding mill price,maize flour mill
Company Information
Company information
Shijiazhuang Huanpai Machine Co.,Ltd is a professional manufacturer of all types of flour milling machine for wheat/maize/corn, Our production capacity is from 10 ton to 500 ton per day. We provide turnkey project of our machienry, including special design, installation instruction, commissioning and training workers.
Our products are exported to Australian, America, Canada, Belgium, Egypt, Algeria, Zambia, Congo, Kenya, Ethiopia, Uganda, Yemen, Tanzania, Tajikistan, Afghanistan, Vietnam, Israel, Mozambique,Kazajastan and other country.
Our Services
Our service
1. One year quality warranty
2. One year free spare parts
3. Overseas engineers service for installation
4. Whole-life after-sales service and free consultation
5. Customized requirements available
6. Technician guide at the site.
7. 24Hr online service
Product description
Product Description
| 6FYDT-50 maize processing equipment line | |
| 1.Production capacity: | 48-53tons maize /24h |
| 2.Power supply: | 135W |
| 3. Container: | 2 container 40feet |
| 4.Products variety: | 1.1) 70% Maize fine flour(40-60mesh) ; 2) 12%-14% of second maize flour; 3) Maize bran and maize germ(this is for animal food) |
| 5. Workshop (L×W×H): | 26×9×7.5m. |
| 6.Installation expenses: | This service is the charged service, Which includes installation, test running, and training local operators. This complete equipment requires two technicians for guiding installation. The buyer should provide for technicians return tickets, local food and boarding, transportation, medical insurance, and the salary of 1’800 USD per man per month. The buyer should directly pay technicians the salary. |
1. cleaning part wheat flour mill
to clean out the middle and small impurity from wheat. e.g., dust, stone, magnetic material, wheat was bitten by insect and so on.Includes beating, screening, destoner, magnetic separator and dampening.this section is make the wheat to prepare for millling part and to protect the machinery as well.
2. milling part
Include different number of mill and sifter to mill the wheat and separate the flour and bran
(1) Mill: mill the wheat to break the integrity by the roller moving
(2) Sifter: to separate the flour and bran, also separate large size and small size to enssure flour quality.
3. Packing part.
The packing part can be manual one also can be auto one, this can be designed according to requirement and machine capacity.
4. PLC controlling system
To controlling the whole set of machinery to work well and showing the process of working
Single machine display
| Roller mill | Plansifter |
 |
 |
| Bran brusher | Damper |
 |
 |
| Purifier | Suction gravity classifying stoner |
 |
 |
Our market
Our products are exported to Australian, America, Canada, Belgium, Egypt, Algeria, Zambia, Congo, Kenya, Ethiopia, Uganda, Yemen, Tanzania, Tajikistan, Afghanistan, Vietnam, Israel, Mozambique,Kazajastan and other country.
The cooperation all over the world
| Our 50ton wheat flour milling machine in Ethiopia |
 |
 |
 |
| Our machine in Zambia |
Freely contact with us if you have any questions about our products.
|
