HZS Fully Environmental-friendly Commercial Concrete Mixer Plant
Green Commercial Concrete Mixing Station is a combination of modern mixing technology, environment protection technology, information intelligent technology and city art, which is embodied in aspects such as environment-friendly, low-carbon and energy-conserving, high-efficient and energy-conserving, intelligent information when it is working. The exhausts made by the production (gas, liquid, solid) and the noise are in accordance with the national standard. The types of Green Commercial Concrete Mixing Equipment developed by NFLG are as follows: HZS120, HZS180, HZS200, HSZ225, HZS250 and HZS300.The station not only tackles the pollution problem but also rise the material utilization ratio. It is win-win for environment benefit and economy benefit and it is a full- covered environment-friendly concrete mixing station.
Parameter :
| Model | HZS120 | HZS180 | HZS200 | HZS225 | HZS250 | HZS300 |
|---|---|---|---|---|---|---|
| Design production capacity （m³/h） | 100 | 150 | 200 | 225 | 250 | 300 |
| Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) | Mixer(twin spiral/twin shaft) |
| Mixer model | JS2000 | JS3000 | JS4500 | JS4500 | JS5000 | JS6000 |
| Power（kW） | 37x2 | 55x2 | 75x2 | 75x2 | 90x2 | 65x4 |
| Output capacity(L) | 2000 | 3000 | 4500 | 4500 | 5000 | 6000 |
| Aggregate size(mm) | ≤80 | ≤80 | ≤80 | ≤80 | ≤80 | ≤80 |
| Aggregate dosage hopper（ semi-under ground ） | 20x4 | 30x4 | 30x4 | 30x4 | 40x4 | 30x4 |
| Aggregate dosage hopper (under ground) hopper capacity （m3） | 4 underground hopper | 4 underground hopper | 4 underground hopper | 4 underground hopper | 4 underground hopper | 4 underground hopper |
| Inclined beltconveyor carrying capacity(t/h) | 500 | 600 | 600 | 900 | 600 | 1200 |
| Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy | Weighing range and accuracy |
| Aggregate scale（kg） | （800-2400）±2% | （1200-3600）±2% | （1600-4800）±2% | (1800-5400）±2% | （2000-6000）±2% | （2400-7200）±2% |
| Sand scale （kg） | （500-1600）±2% | （800-2400）±2% | （1050-3200）±2% | （1200-3600）±2% | （1300-4000）±2% | （1600-4800）±2% |
| Cement scale（kg） | （400-1200）±1% | （600-1800）±1% | （800-2400）±1% | （900-2700）±1% | （1000-3000）±1% | （1200-3600）±1% |
| Fly ash scale(kg) | （130-400）±1% | （200-600）±1% | (250-800）±1% | （300-900）±1% | （300-1000）±1% | （400-1200）±1% |
| Water scale（kg） | （150-500）±1% | （250-800）±1% | （400-1200）±1% | （400-1200）±1% | （400-1200）±1% | （400-1200）±1% |
| Liquid additive scale（kg） | （15-50）±1% | (25-80）±1% | （40-120）±1% | （40-120）±1% | （40-120）±1% | （60-180）±1% |
| Total power consumption（kW）exclude screw conveyor,silo | 155 | 200 | 265 | 265 | 330 | 416 |
| Discharging height （m） | 4.1 | 4.2 | 4.1 | 4.1 | 4.1 | 4.1 |
