Contact    Contact Form    1A,1C
Rated Load    Resistive    6A/250VAC 30VDC
Motor
Operating Power(Resistive)    1500VA 180W
Contact Resistnce(Initial)    ≤100mΩ (gold plated contact ≤30mΩ )
Material    Ag alloy
Electrical Life    ≥60,000 cycles (1800 Ops/h)
Mechanical life    ≥ 10,000,000 cycles (18000 Ops/h)
Operate Voltage( at 23°c)    DC:≤75% rated voltage
Release Voltage ( at 23°c)    DC:≥5% rated voltage
Max. Allowed Voltage ( at 23°c)    110% rated voltage
Insulation resistance    ≥500 MΩ (500VDC)
Coil Power Consumption    3~24VDC(W)    0.17
48~60VDC(W)    0.21
Operate Time    ≤8ms
Release Time    ≤4ms
Dielectric Strength    Between Contacts    1000VAC/1 min (Leakage current 1 mA)
Between Contact and Coil    4000VAC/1 min (Leakage current 1 mA)
Ambient Temperature    -40~+85°c
Humidity    35%~85% RH
Atmospheric Pressure    86-106 KPa
Shock Resistance    10G
Vibration resistance    10~55Hz Dual Amplitude:1.0mm
Install Model    PCB terminal
Weight    6 g
