active line array column speaker system

Model:LA-510
Brand:T.I Reward
Origin:Made In China
Category:Electronics & Electricity / Other Electrical & Electronic
Label:Line Array Column , Column System Speake , Pa Speaker
Price: ¥1 / pc
Min. Order:2 pc
Inquire Now Add to Basket

Member Information

Detail

Guangzhou T.I Reward Audio CO.,LTD

Free MemberGuang Dong - China
Live Chat:Last Online:06 Sep, 2016

Product Description


The LA-510 is a line array column system comprised of ten 5" neodymium magnet transducers housed in an high quality plywood speaker box. The ten closely spaced cone drivers provide true line array characteristics - phase coherence, low distortion and focused listening in both the near field, and at a distance from the speaker.

LA-18 is a 18"subwoofer, specifically designed to reproduce deep bass frequencies with maximum efficiency, speed and impact. It is also ideal for reproducing the concentrated energy of contemporary music environments such as discos, clubs and outdoor shows where extreme level of bass is required.

LA510LA18 line array column speaker 105 column system




Frequency Response     95Hz20kHz ± 3dB

Power handling         450W (RMS) 900W (PEAK)

Sensitivity            101dB(1W@1M)

Max@S.P.L.             127dB(PEAK/1M)

section                10×5"(125mm)neodymium driver

Nominal impedance      8 ohm

Dispersion             110°H×10°V

Speaker cables         LF 1(+)1(-)  HF 2(+)2(-)

Input connectors       2×NL4MP speakon

Dimensions             180×1321×204mm(W×H×D)

Package dimensions     250×1391×274mm/0.07cbm

Enclosure              Plywood

Net weight             17 kg

Gross weight           19 kg

Model

LA-18

TypeSub-bass system

Frequency Response35Hz-500Hz±3dB

Power handling800W(RMS)1600W(PEAK)

Sensitivity104dB(1W@1M)

Max@S.P.L136dB(PEAK/1M)

LF section1×18"(460mm) woofer 100mm

(4in)coil

Nominal impedance8 ohm

Surface finishBlack paint

Input connectors2×NL4MP speakon

Dimensions650×546×780mm(W×H×D)

Package dimensions720×646×850mm/0.40cbm

EnclosurePlywood

Net weight48kg

Gross weight51kg

Applications:

Medium-large scale venues including stadium, concert hall, auditorium, theatre, Music Halls, Night clubs, Large Discotheques, touring show, rental market etc.



Company Profile

Outdoor Sound Reinforcement Sound Equipment Pro Line Array

T.I Reward Audio CO.,LTD is a global designer, manufacturer and distributor of  high quality pro audio equipment, our production line including indoor outdoor line array speaker, pa speaker, pro subwoofer, monitor speaker, power amplifier, processor and wireless microphones. OEM and customized service is well provided for our customers.





Outdoor Sound Reinforcement Sound Equipment Pro Line Array

T.I Reward Audio with the highest lever and most luxury raw material in the world, and offer to clients with the normal Chinese price.



1.Pure Iron System, it's the main part of the speaker driver units, such as pure iron, titanium, using electrical pure iron, high permeability, is the industry's most extravagant speaker material, compared to the speaker than ordinary iron sheet used 80 times to 100 times, particularly low temperature, characterized by a continuous sound particularly good, there is no magnetic circuit eddy current status, linear supple, not in haste.









2. Conical Wood horn, wood horn made from a more high-quality Russian birch plywood in high temperature and pressure, and unit-specific parameters of our own research and development agreement, wooden horn production cost is 5 times that of conventional plastic horn, professional PA system HI FI level production, is characterized by not with vibration woofer cavity interference sound particularly clear, detailed, this wooden horn sound reduction is particularly high.







3.Speaker research and production, our company has independent R & D capability of the speaker, from raw material procurement until the operating instructions issued to the final speaker line QA QC made by our technical team tracking execution. With the development and production of world-class speaker level.

      For example, we strictly control the voice coil wire purity level, especially in the     voice coil made of       glue when we certified by the EU more than 220 degrees Celsius, 100     hours of power test, can           provide relevant information parameters. Our usual cone of high-   quality British UKN cone, he can         better restore and release sound. We use a magnet Y35     quality international standards. T Washer      We use top electrical iron, 900 degrees C after   8 hours-temperature annealing processing, so that        the carbon content close to zero. Our   Speaker Box frame belongs to our specially treated surface          temperature electrostatic     spray, and balanced treatment, such as selvedge position plucked                location, location       washer, we use CNC lathe finishing to ensure that the speaker is not at work          There is an   equilibrium problem. We open with a mold clamping, so that the speaker does not work        exist selvage shedding problem.



We focus on new audio technology, fashion appearance, market flexible structure research. Our PA products in pursuit of high technology, fashion, plasticity characteristics.

Over 20 years of technical experience of our sound engineers are the foremost guarantee to all of our operation. Our electro-acoustic professionals and staffs are working for the company dedicatedly and energetically. Insistent training with serious, systematic and sophisticated QA concept to our staffs had built up solid foundation to our quality as well as to our success in the industry.



T.I Reward audio products ideal for rental market, installation market for events, multimedia, musicals, concert halls, theatres, church and other application …We never stop the music. We can easily meet all requirements for clients in quality, price and box design. Browse & our products & contact us for professional help and advice .
