| Model: | TS800JS 4X4 |
|---|---|
| Brand: | TS;TANGSUN;OEM |
| Origin: | - |
| Category: | Sports & Recreation / Scooters / ATV & Quad |
| Label: | UTV , Gokart , side by side |
| Price: |
-
|
| Min. Order: | - |
| Live Chat: |  | Last Online:24 Oct, 2017 |
JAGUAR 800CC DUNE B Y/GO KART/GAS UTV
800cc GAS UTV :
1. 800cc sport UTV
2.2V91MW, DOUBLE –CYLINDER, 4-STROKE, SOHC, WATER-COOLED
3.600KG curb weight
4.Colored OEM&ODM
800cc gas UTV Feature:
|
ENGINE TYPE |
2V91MW, DOUBLE –CYLINDER, 4-STROKE, SOHC, WATER-COOLED |
|
DISPLACEMENT |
800CC |
|
VALVE CONFIGURATIONS |
8-valve |
|
COMPRESSION RATIO |
10.3:1 |
|
MAX. TORQUE |
73N.m/5000 RPM |
|
MAX. POWER |
44kw/6000 RPM |
|
IGNITION TYPE |
IDI (Inductive Discharge Ignition ) |
|
SPARK PLUG |
NGK DCPR8E |
|
GEAR OIL |
400ml XP-S GL-5 GEAR OIL |
|
TRANSMISSION TYPE |
L/H/N/R |
|
PRODUCT DIMENSIONS |
L2860 mm,W1480mm,H1720mm |
|
CARGO BOX DIMENSIONS |
L780 mm,W1270mm,H230mm |
|
WHEEL SPAN |
1180 mm |
|
WHEEL BASE |
2030mm |
|
FRONT TIRE |
26*9-14 |
|
REAR TIRE |
26*11-14 |
|
GROUND CLEARANCE |
300mm |
|
MINIMUM TURNING RADIUS(MM) |
4600MM |
|
MAX. SPEED |
95km/h |
|
STEERING SYSTEM |
ELECTRIC POWER STEERING |
|
FRONT SUSPENSION |
DOUBLE ARM INDEPENDENT SUSPENSION |
|
REAR SUSPENSION |
DOUBLE ARM INDEPENDENT SUSPENSION |
|
BRAKE SYSTEM |
DUAL HYDRAULIC DISC |
|
FUEL CAPACITY |
26L |
|
CURB WEIGHT |
590kg |
|
CROSS-COUNTRY POWER |
APPROACH ANGLE 800 REMOVED ANGLE 750 PASSING ANGLE 350 |
|
QUANTITY: |
40HQ 12PCS |
|
COLOR: |
GREEN,KHAKI,CARBON GREY ,WHITE (CUSTOM MADE) |
| Payment Terms: | T/T;LC |
|---|---|
| Lead Time: | 35DAYS |
