| Model: | XGQ/HG-12 |
|---|---|
| Brand: | Sharing |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Cleaning Machine |
| Label: | coin washing machine , coin laundry machine , coin washing and dry |
| Price: |
US $3600
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:20 Apr, 2016 |
1. Special designed computer controller of coin operated washer and dryer, which can auto-program for users to choose from common washing, standard washing and strengthened washing and drying.
2. Separated control systems for washing and drying, with coin operated equipment designed for different coins of countries of the world.
3. The number of coin thrown for washing and drying are preset by computer programming which will record the total number of coin thrown.
4. Chemical detergent is automatically put into washing cylinder by three metering pumps following the washing procedures.
5. Water( cold or hot ) inlet and drainage are controlled by solenoid valve.
6. Our machine is a whole structure of overlaying type with the upper part for drying and the lower part for washing.
7. The internal cylinder and outer panel for washing and drying is made of stainless steel 304 material.
8. Energy saving,like water, electric. Water is a precious resource, electric cost is expensive in many countries.
| Model | XGQ/HG-10 | XGQ/HG-12 | XGQ/HG-16 |
| Capacity - kg | 10 | 12 | 16 |
| Washer Cylinder Diameter - mm | 580 | 580 | 640 |
| Washer Cylinder Depth - mm | 380 | 460 | 490 |
| Dryer Cylinder Diameter - mm | 680 | 680 | 720 |
| Dryer Cylinder Depth - mm | 570 | 680 | 680 |
| Wash -rpm | 45 | 45 | 42 |
| Distribution-rpm | 80 | 80 | 80 |
| Medium Extract - rpm | 480 | 480 | 480 |
| High Extract - rpm | 850 | 850 | 850 |
| G-Force | 300 | 300 | 300 |
| Washer Motor Power - kw | 1.1 | 1.5 | 1.5 |
| Washer Frequency Converter Power - kw | 1.1 | 1.5 | 2.2 |
| Washer Electricity Heated Consumption-kw/hr | 6.0 | 9.0 | 9.0 |
| Dryer Motor Power - kw | 0.47 | 0.47 | 0.55 |
| Dryer Electricity Heated Consumption-kw/hr | 7.2 | 9.0 | 12.0 |
| Dimension - mm | 800x1060x2000 | 850x1200x2000 | 1100x1280x2150 |
| Weight-kg | 480 | 550 | 650 |
