| Model: | Self Adhesive |
|---|---|
| Brand: | WEIPAI |
| Origin: | Made In China |
| Category: | Construction & Decoration / Waterproof Materials |
| Label: | bituminous waterproo , waterproof membrane , sbs modified |
| Price: |
US $3.5
/ SQ.MS
|
| Min. Order: | 1000 SQ.MS |
| Live Chat: | Last Online:11 Apr, 2016 |
%51C31_5WNK[]HD.jpg)
high polymer self-adhesive sbs modified bituminous waterproof membrane
GB 23441-2009
|
Cover |
Cover |
Mold |
Thickness |
Width |
Qty. / Roll |
Standard |
|
O N |
O PET |
O I |
O 1.2mm |
O 1 m |
O 10 sq.ms |
O GB 23441-2009 |
|
O PE |
O 1.5 mm |
|||||
|
O Double Adhesive |
O II |
O 2.0 mm |
||||
|
O PY |
O 3.0 mm |
|||||
|
O Single Adhesive |
O 4.0 mm |
|||||
|
N-No Base Felt PY—Polyester |
PE—Polyethylene PET-Polyethylene Terephthalate |
|||||
Product Specification
Self-adhesive modified bitumen waterproof membrane are produced with advanced production technology and equipment. It has a widely prospect new construction waterproof materials. Good self-adhesion, no leaking, cold flexibility, especially in self-adhesion that is unique product in waterproof and application.
high polymer self-adhesive sbs modified bituminous waterproof membrane
|
N-Self-Adhesive Polymer Modified Bitumen Waterproof Membrane |
||||||
|
Item |
Index |
|||||
|
P |
PY |
D |
||||
|
I |
II |
I |
II |
|||
|
Tensile Properties |
Tension (N/50mm)≥ |
150 |
200 |
150 |
200 |
— |
|
Elongation at Max
|
200 |
30 |
— |
|||
|
Asphalt Breaking
|
250 |
150 |
450 |
|||
|
Shank Tear Strength /N ≥ |
60 |
110 |
30 |
40 |
— |
|
|
Heat Resistance |
70 ℃, Slide no more than 2mm |
|||||
|
Low Temperature Flexibility / ℃ |
-20 |
-30 |
-20 |
-30 |
-20 |
|
|
No Cracks |
||||||
|
Impermeability |
0.2Mpa, 120min not permeable |
— |
||||
|
Peel Strength/
|
Between Membranes |
1 |
||||
|
Between Membranes
|
1.5 |
|||||
|
Permeability /Piece ≤ |
2 |
|||||
|
Continued Viscosity /min ≥ |
20 |
|||||
|
Thermal Aging |
Rally Retention % ≥ |
80 |
||||
|
Elongation at Max Tension /% ≥ |
200 |
30 |
400 |
|||
|
Low Temperature Flexibility /℃ |
-18 |
-28 |
-18 |
-28 |
-18 |
|
|
No Cracks |
||||||
|
Peel Strength Between Membranes and Aluminum /(N/mm) ≥ |
1.5 |
|||||
Product Features
1. Self adhesive, safe and environment-friendly;
2.Good tensile strength and elongation;
3.Strong adaptability for substrate shrinkage, deformation and cracks;
4.It will be a high-strength membrane to resist water;
5.Penetration-resisting and corrosion-resisting;
6.Excellent flexibility in low temperature;
7.Strong self healing ability for penetration and cracks
Product Show
Application
Widely used in industrial and civil building roof, basement, toilet waterproof engineering and roof
garden, tunnel, parking lot, swimming pool and other projects of waterproof and moistureproof
Requirements for Construction
1. The base should be dry and clean. Do not work in rainy or snowy day.
2. Do not work under heavy wind. (Temperature need be above 5℃)
3. If it is rain or snow in the process of construction, protective measure to the laid membrane is necessary.
4. All the workers should put on special uniforms to keep safe when installing. There should be equipment for fire controls.
Packaging & Shipping
Company Information
Sichuan Tianqiang Waterproof Insulation Materials Co., Ltd. , a professional waterproofing enterprise, which is focuses on waterproofing material scientific researching, designing, manufacturing, marketing, technical advice and construction services. We have 3 High Polymer waterproofing membrane production lines, 2 APP/SBS Modified bitumen membrane production lines, Self-adhesive membrane production line, Waterproof coating production line. We sincerely welcome friends from all over the world to contact us, visit and cooperate with us.
Certificates and Honors
Our Brand “WEIPAI” was awarded "Famous Brand of Sichuan" in 2013. Our company has got the approval of SGS Certificate, ISO9001 Certificate, ISO14001 Certificate, CTC Certification etc.
Strategic Partners
Why Choose us?
1. Honest supplier to the worldwide buyers
2. Factory, direct supplier, competitive price
3. Know how to control the costing with 30 years producing experience
4. Warm and friendly service and guidance.
5. 2 shifts workers for 24hrs production, high capacity and efficiency.
6. Both small and big orders are welcomed.
7. 24 hours one-to-one on-line service.
FAQ
|
1. Are you manufacture or trading company? |
|
Answer: We are manufacture; our factory is located in Shaqu Industrial Zone, Chengdu City. |
|
2. How long have you been in waterproofing? |
|
Answer: Our company has been in waterproofing industrial for more than 30 years. |
|
3. Can I have samples before order? |
|
Answer: Yeah, Free waterproofing membrane sample is available |
|
4.How long you need to process my order? |
|
Answer: We have stock for all type membrane, we can ship you order in 3 working days. |
|
5.What quality guarantee can I get? |
|
Answer: We have 1 year quality guarantee, please understand we not guarantee for your wrong operation or storage. |
|
6.Can I visit your factory? |
|
Answer: You are welcome to visit us; the airport is Chengdu Shuangliu International Airport. |
|
7.How can I contact you? |
|
Answer: You can reach us by Phone call, Whatsapp, Skype, Email etc., please check our contact information below. |
Contact us
| Payment Terms: | TT LC |
|---|---|
