High Accuracy Handheld Ultrasonic Flow Meter with RS232
Product Description
Four rows of characters display instantaneous flow rate, flow velocity, the cumulative flow, signal state, etc..
Built-in data recorder, can record dates, cumulative flow, signal condition, working time, etc..
OCT output positive, negative, cumulative net pulse signal and the frequency signal (1-9999Hz optional).
RS232 interface is used to glue network detection or export recorded data.
Suitable for all variable sizes of pipes’ flow metering.
The velocity measuring range 0.01 ~ + 32 m/s.
Suitable for steel, stainless steel, cast iron, PVC, FRP, etc. uniform and compact of pipeline.
Upstream of straight pipe section should satisfy 10D, downstream 5D, 30D to the pump outlet (D refers to the pipe diameter).
Built-in Ni-MH rechargeable battery can work continuously more than 10 hours.
Small size (220×92×32mm), portable weight (538g)
| Payment Terms: | 100% T/T in advance available |
| |
Product Image
Img 1
Img 2
Img 3
Img 4
Img 5
