Waist Height Rotate Turnstile with Fence single/double aisle

Core Features:

Bi-directional control
High traffic volumes
Helps employ strict security standards
Internal & external installations
Can be linked with multiple card-reading devices
Cable routes through side frames

Main Functions:

1. With functions of breakdown self check and alarm, easy operation and maintenance.
2. Equipped with standard card read window, external switch button and remote control are available, realizing one-way or two-way controlling.
3. With automatic reset function:When rotate turnstile pole unlocks, it turns 120 degree then automatic reset (lock). Or When there is no access within the fixed time, the system will automatically cancel the user's access permission and automatically close(lock), delay time can be 3 s, 5 s, 10 s, 60 s.
4. Impingement resistant function: Without receiving the start signal, Turnstile pole locks automatically.
5. Anti-trailing function: Turnstile pole rotates 120 degree and then automatically locks, avoiding the trailing.
6. The pole will drop down automatically to evacuate people in the event of an emergency, such as fire, power failure
7. Can be connected with various card-reading devices, and receive the switch signal of the relay.
8. One-way, two-way passing functions, can control visiting personals.
9. With optical working principle, no delay to the input control signals, absolutely avoiding brush a card in a few people
10. By external button, left or right normal open function can be realized in this waist height Rotate Turnstiles.
11. External button can realize drop arm function even when power is on.
12. Realize remote control and management directly through the computer (customized)
13. Control panel can be connected with external counting function Record the number of present, superposition to add, reverse to reduction function(customized).

Technical data:

Housing size:1480*280*1200mm

90 degree

Arm Length:   570mm

Housing material: International 304SS

Process craft:Adopt bending,cutting,welding,polishing,buffing etc.

Working environment: Indoor and outdoor with proof.

Voltage : AC220±10% V,50HZ

Drive motor: DC （50W/12V）

Motor rotation: 1600r/m

Standard input interface: Relay switch signal

MCBF:6million time

Passing speed:60person/minute

Required time for entering to the passing status after power on:3s

Reset time after failure:10s

Working temperature: -40℃—— 80℃

Humidity : :5%--95%
