| Model: | - |
|---|---|
| Brand: | Yonlit |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Telecommunication & Broadcasting / Other Communication Equipment |
| Label: | Tetra Power Amplifie , UHF PA , VHF PA |
| Price: |
US $295
/ pc
|
| Min. Order: | 1 pc |
| Last Online:11 Dec, 2015 |
| No. | Item | Requirements | |
| 1 | Frequency Range | VHF | 135-175MHz |
| UHF | 375-475MHz | ||
| 2 | Gain | 50dB | |
| 3 | Output Power | 25W | 43dBm |
| 50W | 47dBm | ||
| 4 | Gain Adjustable | 31dB | |
| 5 | In-Band Ripple | ≤2dB | |
| 7 | Input/Output VSWR | ≤1.3 | |
| 8 | Working Voltage | 12VDC | |
| 9 | Working Current | 25W | 7A |
| 50W | 12A | ||
| 10 | RF Input/ Output Ports | SMA-Female | |
| 11 | Dimension | 150*90*25 (mm) | |
| 12 | Power Supply | Pull-core Capacitance | |
| 13 | Weight | About 1kg | |
| 14 | To Monitoring function (DB10,Male) | PIN1: GND | |
| PIN3:P/L (Output RF Power; Max voltage:4V) | |||
| PIN5: VSWR (Reflected RF Power, Max voltage:4V) | |||
| PIN7: LE :Enable, High Level: OFF; Low Level: ON | |||
| PIN9: +8V Output | |||
| PIN2: 1dB | |||
| PIN4:2dB | |||
| PIN6:4dB | |||
| PIN8:8dB | |||
| PIN10:16dB | |||
If you are interested with this prodcut, please contact us:
Website: www.yonlit.cn
