TOP Industry Co. (TOPICN), is the market leader in centrifugal casting tube for refining, petrochemical industry and direct reduction plant (DRI), fertilizer, main products including hydrogen generation furnace tube, ethylene cracking furnace tube, tube assembly, tube coil, DRI reformer tube and other centrifugal casting tube and static casting of heat resistant alloy.

Reforming tube for hydrogen generation plant

1.Standard: ASME, ASTM; HG/T 2601-2000; HG/T 3673-2000; GB 13296-2007; NB/T 47008-47010-2010
2. Material: ZG40Ni35Cr25NbM, HP-Nb(MA), G4852 Micro, 1.4852, Hk40, 1.4848
3. OD, Length as customers' requirement
4. Process: Centrifugal casting
5. Quality: Appearance: Coarse with bayberry
6. Packing: Wrapped in bundles by steel strips with reinforced steel or as customers' requirement
7. Delivery time: 30 to 90 days after we signed SALES CONTRACT.
8. Port of departure: Shanghai
9. Certification: ISO9001: 2008
10. Payment: L/C, T/T
11. Reformer tubes used in the refining, petrochemical and fertilizer, DRI industries are manufactured by the centrifugal casting process, the material is heat-resistant austenitic alloy, such as HK -40, HP-40, and HP -Niobium modified materials. A design life of tube is 100, 000 operating hours, it is the criteria for considering retirement of tubes.

Hydrogen generation reformer
The hydrocarbon steam reforming process is the principal industrial process used to manufacture synthesis gas for the production of ammonia, hydrogen and methanol. The heart of this process is the tubular primary reformer where the hydrocarbon feed plus steam is catalytically reacted to produce the synthesis gas. The standard primary reformer system is the tubular reformer where the feed stream passes over the catalyst packed in multiple banks of externally heated tubes. The tubes are heated in a refractory lined firebox which may be top, side, or bottom fired. The feed flow can be down flow or up flow through the tubes. With improvements in tube metallurgy, primary reformers operate at pressure up to 60 bar and tube wall temperatures up to 1000° C. The average heat flux may be as high as 30, 000 BTU/hr. Ft2. The feedstock may vary as natural gas, LPG, or naphtha.
