| Model: | ZQ70,ZQ90,ZQ120 |
|---|---|
| Brand: | - |
| Origin: | Made In China |
| Category: | Textile & Leather / Fabrics / Non-woven Cloth & Industrial Fabrics |
| Label: | Biogas Tank Fabric , Red-mud Biogas , PVC water tank |
| Price: |
US $5000
/ sqm
|
| Min. Order: | 5000 sqm |
| Live Chat: | Last Online:29 Jun, 2015 |
Products Features:
1.Excellent intensity,new materials with technology;
2.Fire retardant,ageing resistance,excellent tensile strength,corrosion and cold resistance;
3.Excellent air tightness,heat absorption,geat preservation,produce biogas more easily;
4.Climate resistance,long life and economic.
_________________________________________________________________________
Foresight Biogas Tank Fabric Specification
|
Item |
Unit |
Test Method |
Type |
|||
|
ZQ70 |
ZQ90 |
ZQ120 |
||||
|
Color(Optional) |
- |
- |
Blue, Red mud, Milk white |
|||
|
Base fabric |
Denier |
ISO1833-25-2013 |
Polyester Fiber |
|||
|
Thickness (Reference) |
mm(±0.02) |
HG/T3050.3 ISO 2286-3 |
0.7 |
0.9 |
1.20 |
|
|
Weight |
gsm |
HG/T3050.3 ISO 2286-3 |
930±30 |
1180±30 |
1500±30 |
|
|
Width |
mm(±5) |
HG/T3050.1 ISO 2286.1 |
2100 |
2100 |
2100 |
|
|
Tensile Strength (Warp/Weft) |
N/5cm |
HG/T2580 ISO 1421-1998 |
2800/2600 |
2800/2600 |
4500/4300 |
|
|
Tear Strength (Warp/Weft) |
N |
GB/T2581-1994 ISO 4767-1-2003 |
350/300 |
350/300 |
800/750 |
|
|
Adhesion Strength |
N/5cm |
HG/T3052-2008 ISO 2411-2000 |
100 |
100 |
100 |
|
|
UV Protection |
- |
- |
Alternative |
|||
|
Low temperature resistant(-30℃) |
℃ |
FZ/T01007-2008 |
No cracks on the surface |
|||
|
High temperature resistant(+70℃) |
℃ |
FZ/T01008-2008 |
≥90 |
|||
|
Acid,alkali and salt corrosion resistance |
672h |
FZ/T01008-2008 |
Appearance |
No bubbles, cracks, delamination, bonding and holes. |
||
|
Tension load holding rate/% |
≥90 |
|||||
|
Cold resistance（-25℃） |
No cracks on the surface |
|||||
All the prices are only for reference. Exact price will be based on the latest quotation.
| Payment Terms: | TT/LC |
|---|---|
