Rosemount 3051TG Gauge Absolute Pressure Transmitter

Model:3051TG
Brand:Rosemount
Origin:Made In United States
Category:Electronics & Electricity / Electronic Instrument / Pressure Gauge
Label:rosemount 3051 , pressure transmitter , transmitter
Price: -
Min. Order:-
Inquire Now Add to Basket

Member Information

Detail

Xiyi Group Co., Ltd.

Biz MemberShaan Xi - China
Live Chat:
点击这里给我发消息Last Online:07 Dec, 2022

Product Description

Features

· Manufactured by Rosemount

· Calibrated spans from 0.3 to 10000 psi

· Up 0.04% accuracy (optional)

· Total performance of ±0.15%

· Installed five-year stability of 0.125%

· Unmatched Dynamic Performance

· Optional PlantWeb Functionality to increase plant productivity

· Responds up to eight times faster than the typical pressure transmitter

Specifications:

output:

4-20 mA with digital signal based on HART Protocol; Low Power, 1-5 V dc with digital signal based on HART Protocol; Low power, 0.8-3.2 V dc with digital signal based on HART Protocol, optional

range:

0-0.3 to 0-10,000 psi

accuracy:

1-5: +/-0.075% of span

power:

4-20 mA: 10.5-55 V dc with no load Low Power: 6-12 V dc with no load

materials:

Sensor Wetted Parts: SST, Hastelloy, Monel, Tantalum, Gold Plated SS, Gold Plated Monel

fluid:

Sensor fill fluid: Silicone, Inert (Halocarbon)

mounting:

Coplanar and Traditional flanges and Adapters: Cadmium and Nickel-plated CS, 316 SST


Price Terms:FOB XI'AN
Payment Terms:TT/LC
Packing:Emerson Standard Package
Lead Time:1week
