Scaffolding step Ladder 8‘x6'5'' Stairs with guardrails | frame scaffold system

Model:YP-SP
Brand:HSS
Origin:-
Category:Construction & Decoration / Building Steel & Structure
Label:system scaffold , step ladder , stair case
Price: US $1400 / TON
Min. Order:19 TON
Inquire Now Add to Basket

Member Information

Detail

Changsha Xiangjia Metal Material Co., LTD

Free MemberHu Nan - China
Live Chat:Last Online:04 Aug, 2020

Product Description

Descriptions:

1.Material:Q235 Q345 steel

2.Model type: 7'x6'5'', 8'x6'5''
3.Type: traditional socket or toggle pin fixed
4.Surface treatment:HDG/ powder coated
5.Color: silver, red, blue, yellow, green or customize
7.Certificate:ISO9001:2000  ISO9001:2008
8.Standard: ANSI standard.
9.Advantage:easy erection, strong loading capacity, safety and stability
10.Usage: Our products are used widely in bridge, tunnel, petrifaction, shipbuilding, railway, airport, dock industry and civil building etc

11.Components: main frame, cross brace, coupling pin, screw jack w/base, aluminum decking, stairway units, side brackets, guardrail post, guardrails, etc.



Specifications Details:

Walk Thru Frame
Commodities and Description OD Weight  (lbs) Lock Type Finish
5'X6'7" Heavy Duty Walk Thru Frame   1.69" 57.86 Speed Lock Powder coated
5'X6'7" Ladder Walk Thru Frame   1.69" 55 Speed Lock Powder coated
5'X6'7"  Walk Thru Frame   1.69" 47.56 Speed Lock Powder coated
3'X4'  Walk Thru Frame   1.69" 24.15 Snap-on Powder coated
3'X5'  Walk Thru Frame   1.69" 30.3 Snap-on Powder coated
3'X6'8"  Walk Thru Frame   1.69" 35.85 Snap-on Powder coated
5'X6'8"  Walk Thru Frame   1.69" 42.87 Snap-on Powder coated
5'X6'4"  Walk Thru Frame   1.69" 49 V Lock Powder coated
3'X6'4"  Walk Thru Frame   1.69" 42.46 V Lock Powder coated
42"X6'4"  Walk Thru Frame   1.69" 39.5 V Lock Powder coated

Box Frame( Mason Frame)
Commodities and Description OD Weight  (lbs) Lock Type Finish
5'x2' SINGLE Box Frame  1.69" 23.54 V-STYLE Powder coated
5'x3' SINGLE Box Frame  1.69" 25.74 V-STYLE Powder coated
5'x4' SINGLE Box Frame  1.69" 31.02 V-STYLE Powder coated
5'x5' SINGLE Box Frame  1.69" 35.47 V-STYLE Powder coated
5’ x 6’ 4” DOUBLE Box Frame  1.69" 38.94 V-STYLE Powder coated
5'x5' SINGLE Box Frame  1.69" 40.84 Snap-on Powder coated
5'x6'8" SINGLE Box Frame  1.69" 49.46 Snap-on Powder coated


Shoring Frame (Heavy-duty)
Commodities and Description OD Weight  (lbs) Lock Type Finish
4'x4' Shoring Frame  1.69" 46.39 Drop Lock Powder coated
4'x5' Shoring Frame  1.69" 53.28 Drop Lock Powder coated
4'x6' Shoring Frame  1.69" 66.73 Drop Lock Powder coated
2'x6'8" Shoring Frame  1.69" 34.8 Snap-on Powder coated
2'x3' Shoring Frame  1.69" 31.28 Speed Lock Powder coated
2'x4' Shoring Frame  1.69" 38.94 Speed Lock Powder coated
2'x5' Shoring Frame  1.69" 46.33 Speed Lock Powder coated
2'x6' Shoring Frame  1.69" 56.72 Speed Lock Powder coated
4'x3' Shoring Frame  1.69" 35.28 Speed Lock Powder coated

Company Information

Why US



Tianjing Heshunchang Scaffolding Co. Ltd is  a leading manufacturer of American-type frame scaffolding,

system scaffoldings and accessories,galvanized steel pipe,Frames,steel props, metal planks, Aluminum planks, and other related products.



• 7 years experience, sales volume reaches 1.5 billion US dollars.
• Good quality control in production process, ISO9001:2008,SGS,BV approved.
• Excellent quality and Competitive price, OEM is available.
• Available in an extensive range of stock or custom size.
• The whole process from material to finished products can be traced.
•Our factory is close to the port-Xingang,Tianjin.



ADTO Scaffolding Accessoreis as below:

1. Ringlock System Scaffold

2. Cuplock Scaffold System

3. Sidewalk Sheds & Shoring Post

4. Frame Scaffold & Pipe scaffolding

5. Tube and Clamps

6. Aluminum decking, Aluminum polywood scaffold deck,

    Steel Scaffold Plank, Wood walkboard, OSHA Scaffold Planks

7. Screw Jack, U-head Jack, base plate



Contacts



Welcome to join in ADTO family, we are ready for any of your construction materials.

  Tel: +86-731-89706529

  QQ: 3224559354

  Cell/whatsapp/wechat: +86-135-10448495

  Attn: Sophia Hou

  E-mail: sophia(at)hsssteel.com




Payment Terms:LC TT

Product Image

Scaffolding step Ladder 8‘x6'5'' Stairs with guardrails | frame scaffold system 1
