| Model: | 20150604 |
|---|---|
| Brand: | FLYGROW |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Heat Exchange & Air Conditioners |
| Label: | fan coil condenser , universal condenser , tubular condenser |
| Price: |
¥100
/ pc
|
| Min. Order: | 100 pc |
| Live Chat: | Last Online:30 Nov, 2015 |
| fin pattern | copper tube diameter(mm) | row space(mm) | hole space(mm) | fin thickness(mm) | fin space | ||||
| flat fin | sine wave with blade fin | smooth sine wave fin | window fin | sasamoid fin | |||||
| A | 7 | 12.7 | 21 | 0.105 | / | / | 1.3 | 1.3 | / |
| B | 7 | 13.2 | 17.6 | 0.105 | / | / | 1.3 | 1.3 | / |
| C | 7 | 12.7 | 20.4 | 0.105 | / | / | 1.3-1.8 | 1.3-1.8 | / |
| D | 7 | 12.7 | 19.05 | 0.105 | / | / | 1.3-1.8 | 1.3-1.8 | / |
| E | 7.94 | 15.88 | 25.4 | 0.105 | 1.8-3.0 | 1.8-3.0 | 1.8-3.0 | 1.8-3.0 | / |
| F | 7.94 | 19.05 | 22 | 0.105-0.13 | 1.4-3.0 | 1.4-3.0 | 1.4-3.0 | 1.4-3.0 | / |
| G | 9.52 | 22 | 25.4 | 0.105-0.13 | 1.6-3.2 | 1.6-3.2 | 1.6-3.2 | 1.6-3.2 | / |
| H | 9.52 | 22 | 25.4 | 0.18-0.4 | 3.5-6.35 | / | / | / | / |
| I | 9.52 | 21.65 | 25 | 0.105-0.18 | 1.6-3.2 | 1.6-3.2 | 1.6-3.2 | 1.6-3.2 | / |
| J | 9.52 | 21.65 | 25 | 0.15-0.24 | 3.2-6.35 | 3.2-6.35 | 3.2-6.35 | / | / |
| K | 12.75 | 27.5 | 31.75 | 0.115-0.15 | 1.5-3.5 | 1.5-3.5 | 1.5-3.5 | 1.5-3.5 | 1.6-3.2 |
| L | 15.88 | 33 | 38.1 | 0.115-0.15 | 1.5-1.0 | 1.5-4.0 | 1.5-4.0 | / | / |
| M | 15.88 | 34.64 | 40 | 0.115-0.15 | / | 2.6-3.5 | 2.6-3.5 | / | / |
| Payment Terms: | L/C or T/T |
|---|---|
