| Model: | JX35-GF108-B |
|---|---|
| Brand: | OEM |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Components / Display Parts |
| Label: | touch screen , touch panel , touch display |
| Price: |
US $1.7
/ pc
|
| Min. Order: | 3000 pc |
| Live Chat: | Last Online:17 May, 2021 |
Customized Capacitive Touch Screen Specifications:
Cover Outline: 68.69(W) x 108.48(H) x 0.95 mm
Active Area: 48.96(W) x 73.44(H) mm
Working Voltage: 2.8 V DC
Driver IC: FT6206
Hardness: 6H
Response Time: 10 ms. Maximum
Activation Force: 10-50 grams per square centimer
Positional Accuracy: 3mm maximum
Light Transmission: Film +Glass>87%
Scratch Resistance: 3H pencil hardness
Life Expectancy: Over 1 million
Operating Temperature: -20º C ~+70 C
Storage Temperature: -30º C ~ +80 C
Choices of Glass Thickness: 0.7mm, 1.1mm, 2.0mm, 3.0mm, 5.5mm, Single film, double film selectable
| Price Terms: | FOB shenzhen |
|---|---|
| Payment Terms: | TT |
| Packing: | Foam Box, carton |
| Lead Time: | 30 days |
| Standards Certificate: | RoHS, ISO9001:2000 |
| Specifications: | Cover Outline: 68.69(W) x 108.48(H) x 0.95 mm Active Area: 48.96(W) x 73.44(H) mm Working Voltage: 2.8 V DC Driver IC: FT6206 Hardness: 6H Response Time: 10 ms. Maximum |
| Export Markets: | Western Europe, USA |
| Payment Details: | TT in advance |
| Min Order: | 3000 pcs |
| Ship Date: | 30 days |
| Standard Met: | RoHs, ISO9001 |
