~Technical specifcation

Operation

Control mode

Keyboard/extermal terminal/RS485 communication


Starting mode

Current limiting/voltage/keavy load


Start and stop time

Can be set digitally


Start delay

Can be set digitally


Emergency stop

Stop the output of the soft starter


Limiting current

The starting current should be lower than the limiting current if the soft starter

is operating under current limiting or heavy load mode


Starting voltage

The starting voltage can be set digitally if the soft starter is operating under

voltage mode


Load control

Possibility to check accidents including belt tripping


Autonmatic restart

Autonmatic restart after breakdown


Fault output

Contact output AC 250V 1A ;DC30V 1A


Multi-function relay output

Start delay, Start,Operation,Stop,Full stop restart


Analogue output

0～20mA / 4～20mA  available


Portection function

Portection of soft starter

Protecting from overload,overcurrent,overheat,unbalanced three phase,

missing phase,under loading,extemal fault,etc


Warning of soft starter

Emergency stop,under loading,restart,etc


Display

Keyboard

Operation information

Operation,stop and fault warnings during standby,start delay and starting


Protection

Protect the parameters from being modified


Application conditions

Application category

AC-53b


Rated insulation voltage

660V

Rated impulse withstand voltage

4KV


Protection degree

IP20


Environment conditions

Ambient temperature

-10℃~40℃


Storage temperature

-20℃~65℃


Storage temperature

Maximum90%RH(No condensation)


Ambient humidity

Below 1000m;below 5.9m/s(=0.6g)


Altitude/vibration

Without corrosive gas,flammable gas,oil mist,dust or others


Cooling

Natural air cooling
