| Model: | 04 |
|---|---|
| Brand: | jianfeng |
| Origin: | Made In China |
| Category: | Industrial Supplies / Construction Machine |
| Label: | multi function brick , brick machine seller , china brick machine |
| Price: |
US $26000
/ set
|
| Min. Order: | 1 set |
| Live Chat: | Last Online:18 Dec, 2023 |
JF-QT-5-20B
No.1 Production output introduction:：
|
Product specification (L×W×H) |
Model number |
Per hour yield |
Produce period |
|
225*112.5*60/80mm Interlock brick /S shape |
18 Pieces |
3240 Pieces |
20 Second/Time |
|
200*100*60/80mm Hollandbrick |
20 Pieces |
3600 Pieces |
20 Second/Time |
|
200*163*60/80mm H Shape brick |
12 Pieces |
2160 Pieces |
20 Second/Time |
|
240*115*53mm Standard brick |
32 Pieces |
5760 Pieces |
20 Second/Time |
|
390*190*190mm Hollow brick |
5 Pieces |
900 Pieces |
20 Second/Time |
|
240*115*90mm Multihole brick |
18 Pieces |
3240 Pieces |
20 Second/Time |
|
1000*150*300mm Curbstone |
1 Piece |
90 Pieces |
35 Second/Time |
No 2. Parameter
|
Ordinal number |
Item |
Parameter |
|
1 |
Actuating shock force |
78KN |
|
2 |
Frequency of shock |
5000(Time/Minute) |
|
3 |
Amplitude |
15mm |
|
4 |
Noise |
85db(A) |
|
5 |
Shock time |
7(Second/Time) |
|
6 |
Overall dimension |
3970×1830×2350(mm) |
|
7 |
Installed capacity |
28.2KW |
|
8 |
Weight of complete machine |
5T |
|
9 |
Maximum pressure |
10T |
|
10 |
Give plank size |
1150×570×20(mm) |
|
11 |
Operation number |
10members |
|
12 |
Use a ground of area |
≥4000 m2 |
No 3.Features:
1. Professional heat elimination technology to make sure machine works in good condition.
2. Changing any moulds can make different kinds of bricks and blocks.
3. Automatical operation for pallet feeding, aggregating, vibrating, pressing and brick receiving , and several matched equipments are for customer’s choose to save more labor force.
4. High density steel for machine frame, advanced heat treatment for spare parts and moulds, make sure the high quality of machine and improve the using lifetime.
5. Easier for operating, maintainance and changing parts, which makes machine working all year round without wasting time on maintainance.
| Payment Terms: | L/C T/T |
|---|---|
