Easy operation chamber annealing furnace for copper wire

Model:RX3-30-9
Brand:Zhongli
Origin:Made In China
Category:Industrial Supplies / Other Industrial Supplies
Label:chambe rfurnace , chamber oven , annealing furnace
Price: US $3800 / pc
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Xinxiang Zhongli Furnace Industry Co., Ltd.

Free MemberHe Nan - China
Live Chat:Last Online:01 Feb, 2016

Product Description

 Easy operation chamber annealing  furnace for copper wire

Brief:

RX3 series box typeresistance furnaceis standard energy-saving batch type furnace, with characteristic of low heat conduction and heat capacity, excellent thermal stability and thermal insulation, good heat preservation effect and temperature uniformity, mainly used for high chromium, high manganese steel castings, ductile iron, roll, steel ball, crusher hammers, wearing plate, flange and various mechanical parts for quenching, tempering, annealing and normalizing heat treatment, etc. Can also suitable for metallic material heat treatment in various colleges, universities and research institutes.

Main technical parameters:

Model

Rated powerKW

Rated voltage (V)

Rated temperature

phase

Furnace hearth sizeL*W*H)(mm

Max. loading capacity kg)

Weight

(kg)

RX3-15-9

15

380

950

3

650*300*250

80

1100

RX3-30-9

30

380

950

3

950*450*350

200

2000

RX3-45-9

45

380

950

3

1200*600*400

400

2500

RX3-60-9

60

380

950

3

1500*750*450

700

4500

RX3-75-9

75

380

950

3

1800*900*550

1200

5200

RX3-20-12

20

380

1200

3

650*300*250

50

1400

RX3-45-12

45

380

1200

3

950*450*350

100

2210

RX3-65-12

65

380

1200

3

1200*600*400

200

2600

RX3-90-12

90

380

1200

3

1500*750*450

400

3900

RX3-115-12

115

380

1200

3

1800*900*550

600

4900

RX3-14-13

14

380

1350

3

520*220*220

50

635

RX3-25-13

25

380

1350

3

600*280*300

80

1200

RX3-37-13

37

380

1350

3

810*550*370

100

1920

Remark

1. The price is only for reference. Exact pricing is according to the product final production.

2. The furnace hearth size is customizable according to the demand of customer






Payment Terms:TT/LC/DP/DA
