CT-C-I Direct fired dryer

Model:CT-C-I
Brand:FENGXIANG
Origin:Made In China
Category:Industrial Supplies / Food, Beverage & Cereal Machine
Label:Fruit and vegetable , Multi-layer oven , Food air dryer
Price: -
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Zhaoqing Fengxiang Food Machinery Co., Ltd.

Biz MemberGuang Dong - China
Live Chat:
点击这里给我发消息Last Online:20 Sep, 2021

Product Description



Working video:http://v.youku.com/v_show/id_XMzM0NzQ0NzgyMA==.html?spm=a2h3j.8428770.3416059.1



Model: CT-C-I dual door double car dryer (available in various specifications)

Product overview:

CT-C series hot air circulation oven is equipped with low noise high temperature resistant axial flow fan and automatic temperature control system, the whole circulation system is completely closed. The thermal efficiency of the oven has been improved from 3 ~ 7% of the traditional oven to 35% and 45%. The highest thermal efficiency can be up to 50%. The design of the oven is successful. The hot air circulation oven of our country has reached the advanced level at home and abroad, saving a lot of energy for our country and improving the economic benefit of the enterprise. In 1990, the industry standard was issued by the State Administration of Medicine. The uniform model is RXH.



Product applications:

Hot air circulation oven is suitable for heating, curing, drying and dehydrating materials and products in pharmaceutical, chemical, food, agricultural and sideline products, aquatic products, light industry, heavy industry, etc., such as raw materials, traditional Chinese medicine, traditional Chinese medicine, Chinese medicine, extract, powder. Granules, granules, water pills, packaging bottles, pigments, dyes, dehydrated vegetables, dried melon and fruit, sausages, plastic resins, electrical components, baking paint, etc.

Typical dried materials are: garlic slices, pumpkin, carrots, konjac, yam, bamboo shoots, onions, apples and so on.



Main parameters:

Model Dimension(mm) Power Eachamoutn of drying Consumed steam Cooling aera Air volume Upper and lower temperature Baking plate Drying car
CT-C-I 2300*1200*2000 0.45KW

120KG

18KH/H 20㎡ 3450㎡/h +-2°C 48 2
CT-C-II

2300*2200*2000

4460*1200*2290

0.9KW 240KG 36KH/H 40㎡ 6900㎡/h +-2°C 96 4
CT-C-III

2300*3200*2000

3430*2200*2000

1.35KW 360KG 54KH/H 80㎡ 10350㎡/h +-2°C 144 6
CT-C-IV 4460*2200*2290 1.8KW 480KG 72KH/H 100㎡ 13800㎡/h +-2°C 192 8














Price Terms:FOB Guangzhou or Shenzhen(or named by client)
Payment Terms:TT/LC or Cash
Packing:By stander exporting plywood case, well protected while transporting.

Product Image

CT-C-I  Direct fired dryer  1
Img 1
CT-C-I  Direct fired dryer  2
Img 2
CT-C-I  Direct fired dryer  3
Img 3
