|Origin:||Made In China|
|Category:||Consumer Electronics & Lighting / Commerce & Finance Electronics / Finance Electronics|
|Label:||Given change kiosk , Bill recycle kiosk , coin change kiosk|
|Min. Order:||1 pc|
Given change touch all-in-one bill payment kiosk
The payment kiosk is an easy to use machine and allows customers to pay their
bill very quickly without any interaction with any employee. It is a simple user
friendly machine that contains detailed instructions on how it works. Customers
have to simply follow the instructions, fill the information in the bill or scan the
coded portion of the bill and then insert the cash. After this, they will get a receipt
from the payment kiosk.
1. 19''durable all-in-one bill payment kiosk cabinet
2. Powerful Embedded computer
3. 19''grade A+ LED monitor
4. operating system available, internet access
5. Thermal printer, payout and coin hopper
Notes: the above components could be order seperately, you are welcome
to order monitor only, or cabinet only. More information, please feel free
to contact me.
1) Touch Panel
a. Resistive, SAW and Infrared available.
b. Resolution: 4096*4096
c. Deviation of Error: ±<1.0%
d. Surface Hardness: Mohs' hardness rating of 7
e. Hitting Life Expectancy: 50,000,000 cycle times
f. Operating Force: Touch force less than 100g(adjust allowed)
g. Support software: Windows, Linux, Android...
h. Transmittance: above 95%...
i. Surface: 3mm glass
2) 19 inch LED monitor(100% new LG or Samsung monitor, Grade A+ monitor)
a. Resolution: 1280x1024
b. Brightness: 300cd/2
c. Contrast ration: 1000: 1
d. Contact Bounce: 5ms
e. Ratio: 4:3 or 16 : 9
f. lifelong: more than 50 000 hours
3) Powerful Computer
a. CPU: Intel J1900 2.0ghz CPU
b. low power and stable industrial mainboard
c. Storage: 120GB SSD, HDD available
d. RAM: Kingmax DDRIII 4GB(optional)
e. Ports: USB ports, RS-232 ports, ports for mouse
f. load speaker, cooling fan, power supply, Integrate graphics card, vedio card...
Thermal printer, smart payout and coin hopper
Power supply: AC110V-240V, 50/60HZ
Working temperature: -15 - 65℃, Working humidity: 20%-80%
Storage temperature: -20 - 60℃, Storage humidity: 10%-95%
6.Cabinet and computer:
Surface: Metal baking varnish(5 layers)(color optional)
Material: First class electrolysis plate, Cold rolled steel plate
Multimedia system: Stereo electronic effects, Magnetic proof
Inteface: RJ45/RJ11 network interface
Optional devices for this all-in-one interactive kiosk:
1. Digital camera, Web camera
2. RFID card reader, IC smart card reader
3. Pinpad with 16 keys, 3G module
4. UPS(10~20mins)for power supply
We are able to provide the customized kiosk, please let us know you requirement if you need to modify for the design and the Peripheral device
Before we send the kiosk to you, in order to make sure the kiosk run well
after you get it, we will test at least 24 hours for each kiosk.
1. 1 year warranty for enclosure.
2. 1 year warranty for electrical parts
3. For mass goods, we will offer some free spare parts of electrical device.
Warm welcome to contact me to get more information, :).
|Price Terms:||EXW price|
|Payment Terms:||TT/Paypal/Escrow/Western Uniom|
|Packing:||foam, carton, wooden case|
|Lead Time:||Usually 15 days after deposit received for sample|
|Standards Certificate:||CE, Rohs, FCC|
