802.11n 300M VoIP Router with 1FXS and HNAT

Model:G801
Brand:Flyingvoice
Origin:Made In China
Category:Electronics & Electricity / Telecommunication & Broadcasting / Other Communication Equipment
Label:voip router , fxs voip router , wireless voip router
Price: US $48 / pc
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Flyingvoice Technology Co., Ltd.

Free MemberBeijing - China
Live Chat:Last Online:24 Nov, 2014

Product Description

Quick Details

* 1 10M/100M port(WAN), 4 10M/100M RJ45 (4 LAN)

* 1 FXS port

* IEEE802.11n 2T2R 300Mbps WiFi

* 5dBi external antenna

* Hardware NAT(HNAT) engine with 100Mbps NAT/NAPT speed

* WiFi throughput is above 160Mbps in MAX

* Real time FAX over IP via T.38 and T.30 FAX with G.711

* PESQ is above 4.4 in G.711, PESQ is above 3.7 in G.729

* Field proven compatibility and stability

* Auto-provisioning: TFTP/HTTP/HTTPs

* TR-069, SNMP

Specifications

Hardware Features
Interface 4 10/100Mbps LAN ports
1 10/100Mbps WAN port
1 FXS port
2 5dB Antenna for IEEE802.11n 2T2R Wireless
1 Power set
Power Supply AC Input : 100-240v, 50-60Hz;  DC Output: 5V, 2A
Environmental  Operation Temperature: 5~45 Degree C
Storage Temperature: -25~85 Degree C
Relatively Humidity: 10%~90% No Condensing
Shock: Up to 75cm Drop upon package
Dimension (L)180×(W)110×(H)30mm
Unit Weight  338g(without package)



Software Features
Audio Codec Features G.711 (A-law, u-Law)with PAMS above 4.3
G.729A/AB with PAMS above 4.0
Adaptive Jitter Buffer Management
Voice Activity Detection
Comfort Noise Generation
Echo Cancellation
T.30 FAX with G.711
Real time FAX over IP via T.38
Protocols SIP V2 (RFC 3261,3262,3263,3264)
Backward Compatible with RFC2543
Session Timer (RFC4028)
SDP (RFC2327)
RTP/RTCP (RFC1889 and RFC1890)
NAPTR for SIP URI Lookup (RFC2915)
STUN (RFC 3489)
ARP/RARP (RFC 826/903)
SNTP (RFC 2030)
DHCP/PPPoE
PPTP/L2TP VPN
HTTP Server for Web Management
TFTP/HTTP for Auto Provisioning
Message Waiting Indicator (RFC3842)
DHCP Option Codes for SIP (RFC3361)
DNS/DNS SRV (RFC1706 and RFC 2782)
IEEE802.1Q VLAN/802.1p and DSCP
Management Firmware Upgradeable
Web Management Interface
IVR-driven Management Interface
Local and Remote Syslog (RFC3164)
Auto Provisioning
SNTP Time Synchronization
Multiple User Level
SNMPv2
TR069
Telnet
System Log: local log and remote log
Wireless 802.11b/g/n support
4 SSID
Static WEP (64/128bit)
Dynamic WEP (64/128bit)
AES (CCMP/TKIP)
MAC Certification
WEP certification
WPA-PAK/WPA-PSK (2.0)
WPA/WPA2
AS Isolation and MBSSID AP Isolation
WMM
WDS
WPS
Station list
Radius certification and billing
MAC Filter (different from MAC Filter)
Applications Support NAT mode and Bridge mode
Support DDNS
MAC address cloning
SIP proxy redundancy
NAT Traversal by STUN
Built-in Wired speed NAT Router
DHCP Server and Client
IP conflict detection
VLAN
Flow Control
VPN Pass through (PPTP,L2TP and IPSec)
Port forwarding and DMZ host
Rate Limit per port
Broadcast Storm Control
Classification by physical port, IP port, 802.1p,DSCP and TCP/UDP port
Marking by 802.1p and DSCP
MAC filter per port
Packer filter for port, IP address, protocol and physical port
Firewall defend attack and UDP flooding
Call Features 3-way Conference
Music on hold
DTMF Relay: In-band, Out-band and SIP INFO
Call Hold
Call Forwarding
Call Mute
Call Transfer
Call Waiting
Speed Dial
Caller ID and CWCID
QoS Layer 3
Real time fax over IP via T.38
T.30 FAX with G.711
Dial Plan
Black List
Call Log
Dial Plan
DTMF Mode: Inband, Outband and SIP Info




Product Image

802.11n 300M VoIP Router with 1FXS and HNAT 1
Img 1
802.11n 300M VoIP Router with 1FXS and HNAT 2
Img 2
802.11n 300M VoIP Router with 1FXS and HNAT 3
Img 3
802.11n 300M VoIP Router with 1FXS and HNAT 4
Img 4
802.11n 300M VoIP Router with 1FXS and HNAT 5
Img 5
