HY-QT5-20 interlock brick making machine 1
  • HY-QT5-20 interlock brick making machine 1

HY-QT5-20 interlock brick making machine

Model:HY-QT5-20
Brand:HY
Origin:Made In China
Category:Industrial Supplies / Construction Machine
Label:brick making machine
Price: US $200000 / set
Min. Order:1 set
Inquire Now Add to Basket

Member Information

Detail

Shanghai Huayu Machinery Manufacturing Co.,Ltd

Free MemberShang Hai - China
Live Chat:Last Online:25 Jan, 2015

Product Description

  • Condition: New
  • Type: Multifunctional brick machine
  • Brick Raw Material:cement,concrete,flyash,slag, mineral waste residue and others
  • Processing: Brick Production Line
  • Method: Hydraulic pressure and Vibration
  • Automatic: Yes
  • Capacity: 43200bricks/day
  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: HY concrete block making machine price
  • Model Number: HY-QT5-20
  • Voltage: 380V
  • Power: 23kw
  • Dimension(L*W*H):2400*2380*2570mm
  • Certification:ISO9001:2000&CE
  • Warranty: one year
  • After-sales Service Provided:Engineers available to service machinery overseas
  • Quality: world class concrete block making machine price
  • Experience: More than 20 years
  • Exported: More than 50 contries
  • Moulding-Cycle: 20-25s
  • forming area: 1000*500mm
  • Spare parts: Supply
  • After-sale service: For whole using life
  • Training(free): Provide professional training to your staff
  • Installation(free): Under our engineers guide
  • Weight: 5.2t

Packaging & Delivery

Packaging Details: Wooden case/Container/Bare
Delivery Detail: 25 days after receiving deposit

A)The concrete block making machine is multi-used. It can satisfy all the needs of the market.This block machine can low the investment risk for the user in the largest extent. It can produce hollow bricks, standard bricks,square bricks.river bricks ,pathway bricks,road shoulder and so on .



B) The list of production capacity and Technical parameters.

product

Specifications(mm)

Bricks/mould

Bricks/day(8 hours)

Bricks/year(300days)

Pathway brick

200×100×60

18

22500

6750000

Hollow block

390×190×190

5

7200

2160000

Standard brick

240×115×53

30

43200

12960000

Multi-hole brick

240×115×90

16

23040

6912000





Exciting force

70KN

Vibrational frequency

4800times/min

Total power

23KW

Molding cycle

Less than 25s(double material)

Pallet size

1030×600×25(mm)

Host size

5800×3000×2800(mm)

Forming Area

1000×500(mm)

Height of molding

40-200(mm)

Host weight

5.2T







NO

The List of the whole line

Pcs

1

Molding machine

1

2

Mixer

1

3

Belt conveyor

1

4

Block conveyor

1

5

Common mould

1

6

Hydraulic station

1

7

Pallet

1500

8

Pallet feeder

1

9

Stacker

1



C) HY-QT5-20 concrete block making machine other information.

1. Area: Workshop area: 60-200m2, all factory area 1500-6000m2, the actual land according to the local situation

2. Workers : four to eight.

3. Ratio of raw material:cement 8%-10% sand 30%-40% stone:50%-60%,about cement :sand : stone is1:4:5.

4.hollow block weight:

(390*190*190) :17KG,(190*140*190):13.5KG,(390*90*190):10KG,

Standard brick(240*115*53):3KG

5. raw material consumption per day:80T

6. water consumption per day:3%-5% of raw material Weight.

D)HY-QT5-20 concrete block making machine guarantee:

Our hollow block making machine is of one year guarantee,during the period we could supply spare parts if they are broken.

E)HY-QT5-20 The pressure of the brick:

Hollow blocks can reach 10-30Mpa,Solid bricks can reach 30-50Mpa,so they have a high pressure,can be used widely.

F)HY-QT5-20 concrete block making machine can produce different size briciks by changing the mould:



Hollow Blocks,Solid Standard Bricks,Blind-hole Bricks,vias brick,Insulation layer.



Pathway bricks,Square bricks, Lawn bricks



The automatic production line which can produce 30,35,40 million autoclaves bricks per year



NOTE:1)Accept consultation from customers and Provide design proposal of factory to customers.
             2)Send our engineers to insall and fix equipments for customers and train your staff .
             3)One year guarantee and service for whole using life.
